Type: TCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave)

Frequency: 32.000000 MHz
Supply Voltage (VDD): +3.3 ±5%
Input Current: 2.0 mA max.

Frequency Stability vs Temperature Range: ±0.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.3 ppm max,
Frequency Stability Vs Load (±5%). ±0.3 ppm max.
Aging: ±1.0ppm max.

Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C

RoHS: Pb free - 2011/65/EU (RoHS 2) compliant

Package Unit: 3000pcs/reel

'-
Type: TCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave)
-
Frequency: 32.000000 MHz
Supply Voltage (VDD): +3.3 ±5%
Input Current: 2.0 mA max.
-
Frequency Stability vs Temperature Range: ±1.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm max,
Frequency Stability Vs Load (±5%). ±0.3 ppm max.
Aging: ±1.0ppm max.
-
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C
-
Phase noise (typical):
... -80 dBc/Hz at 10 Hz offset
... -110 dBc/Hz at 100 Hz offset
... -130 dBc/Hz at 1 kHz offset
... -140dBc/Hz at 10 kHz offset
... -140dBc/Hz at 100 kHz offset
... -145dBc/Hz at 1 MHz offset
-
RoHS: Pb free - 2011/65/EU (RoHS 2) compliant
-
Package Unit: 3000pcs/reel

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
-
Series: Oscillator SMD5032-M4 / QPS5
Type: TCXO-SMD5032-M4
Frequency: 16.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±10%
Input Current: 6 mA max.
Frequency Tolerance: ±2.5 ppm
Output Logic / Output Load: Clipped Sine Wave / 10kΩ// 10pF
Operating Temperature: -20°C to +70°C
Storage Temperature: -55°C to +125°C
Phase Noise at 12,80 MHz: -125dBc/Hz at 100 Hz, -145dBc/Hz at 1 kHz, -150dBc/Hz at 10 kHz
Start-up Time: ≤ 2 ms
-
Package Unit: 1000pcs/reel

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
Series: Oscillator SMD5032-M4
Type: TCXO-SMD5032-M4
Frequency: 20.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±10%
Input Current: 6 mA max.
Frequency Tolerance: ±2.5 ppm
Output Logic / Output Load: CMOS / 15 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -55°C to +125°C
Phase Noise at 12,80 MHz: -125dBc/Hz at 100 Hz, -145dBc/Hz at 1 kHz, -150dBc/Hz at 10 kHz
Start-up Time: ≤ 2 ms
Package Unit: 1000pcs/reel

'-
UTECH, TCXO, SMD5032-M4, 22.000000 MHz, 3.3V, 2.5ppm, -30°C/+85°C

'-
Series: Oscillator SMD2520-M4
Type: TCXO - CMOS Output
Frequency: 40.000000 MHz
Supply Voltage (VDD): +2.8 VDC ±10%
Input Current: 5.2 mA max.
Frequency Tolerance: ±2.0 ppm
Output Logic / Output Load: CMOS / 15 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -55°C to +125°C
Phase Noise at:-145dBc/Hz at 10 kHz
Start-up Time: ≤ 10 ms
Package Unit: 3000pcs/reel

Type: TCXO-SMD7050-M4 - CSW Output (Clipped Sine Wave)

Frequency: 14.745600 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 2 mA max.

Frequency Stability vs Temperature Range: ±2.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.3 ppm max,
Frequency Stability Vs Load (±10%). ±0.3 ppm max.
Aging: ±1.0ppm max.

Output Logic / Output Load: CSW Clipped Sine Wave / 10 kOhm, 10 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C
Phase noise (typical): -130dBc/Hz at 1kHz offset
Start-up Time: ≤ 2 ms
Package Unit: 500pcs/reel

Type: TCXO-SMD7050-M4 - CSW Output (Clipped Sine Wave) | PT75P-3C253F

Frequency: 14.745600 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 3 mA max.

Frequency Stability vs Tolerance at +25°C: ±1.0 ppm max.
Frequency Stability vs Temperature Range: ±2.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm max,
Frequency Stability Vs Load (±10%). ±0.2 ppm max.
Aging: ±1.0ppm max.

Output Logic / Output Load: CSW Clipped Sine Wave / 10 kOhm, 10 pF
Output Level: 0.8 V p-p min
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C
Phase noise (typical): -135dBc/Hz at 1kHz offset
Start-up Time: ≤ 2 ms
Package Unit: 500pcs/reel

'-
UTECH, TCXO, SMD5032-M4, 22.000000 MHz, 3.3V, 2.5ppm, -30°C/+85°C

Manufacturer: Utech Electronics Technology Co., Ltd.

Type: Oscillator VCTCXO-SMD2016-M4
Frequency: 39.000000 MHz
Supply Voltage (VDD): +2.8 VDC ±5%
Input Current: 1.8 mA max.

Frequency Tolerance: ±2.7 ppm
... Frequency tolerance: ±1.5 ppm @+25°C
... Frequency/temperature characteristics: ±1.0 ppm
... Frequency/load coefficient: ±0.1 ppm
... Frequency/voltage coefficient: ±0.1 ppm
... Frequency aging: ±1.0 ppm

Frequency control range: ±8.0 ppm to ± 12.0 ppm at VC =1.4V±1.0V (VCC =2.8V)

Output Logic | Output Load: Clipped Sine Wave | 10kΩ / 10pF ±10%
Operating Temperature: -40°C to +85°C
Storage Temperature: -40°C to +90°C

Start-up Time: ≤ 1 ms

Package Unit: 1000pcs/reel

EPSON
X1G005441031612
TG2016SMN 48.000000MHZ MCGNNM

Case Size: Oscillator SMD2016-M4 (2.0 × 1.6 × 0.73 mm)
Series: TG2016SMN
Type: VCTCXO - CSW Output (Clipped Sine Wave)
Frequency: 48.000000 MHz
Supply Voltage (VDD): +2.8 ~ +3.3 VDC
Input Current: 2.0 mA max.
Frequency Tolerance (at +25°C): ±1.5 ppm
Frequency Stability vs Temperature Range: ±0.5 ppm
Frequency Stability Vs Supply Voltage (±5%): ±0.1 ppm
Frequency Stability Vs Load (±10%). ±0.1 ppm
Frequency control range: ±8.0 ppm to ±12.0 ppm
Symmetry: 50%±5%
Aging max.: ±1.5ppm
Output Logic / Output Load: CSW - Clipped Sine Wave
Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C
Start-up Time: ≤ 2 ms

Package Unit: 250 pcs/reel

SUZHOU UTECH TECHNOLOGY CO.,LTD

Type: Oscillator VCTCXO-SMD2520-M4
Frequency: 64.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 2.0 mA max.

Frequency Tolerance: ±1.0 ppm
... Frequency tolerance: ±1.0 ppm max. @+25°C
... Frequency Stability Vs Temperature Range: ±0.5 ppm max
... Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm max
... Frequency Stability Vs Load (±10%): ±0.2 ppm max
... Frequency aging: ±1.0 ppm/year max

Absolute Pulling Range (APR): ±20 ppm min
Control Voltage Range: 1.65V±1.0V
Output Waveform: Clipped Sine wave
Output Load: 10 KΩ // 10 pF
Start-up Time Vs frequency 2.0 ms max within ±1.0 ppm

Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C

Phase Noise
... 10Hz Offset: -70 dBc/Hz
... 100Hz Offset: -105 dBc/Hz
... 1KHz Offset: -125 dBc/Hz
... 10KHz Offset: -145 dBc/Hz
... 100KHz Offset: -155 dBc/Hz

Package Unit: 1000pcs/reel

Manufacturer: Utech Electronics Technology Co., Ltd.

Series: Oscillator SMD3225-M4 / QZS3
Type: VCTCXO-SMD3225-M4
Frequency: 19.200000 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 2.0 mA max.
Frequency Tolerance: ±1.5 ppm

Output Logic | Output Load: Clipped Sine Wave | 10kΩ / 10pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C

Absolute Pulling Range (APR): ±20 ppm min., ±30ppm max.
Control Voltage Range: 1.65V ±1.0V

Phase Noise at 12,80 MHz:
-90dBc/Hz at 10 Hz
-115dBc/Hz at 100 Hz
-128dBc/Hz at 1 kHz
-145dBc/Hz at 10 kHz
-149dBc/Hz at 100 kHz
-150dBc/Hz at 1 MHz

Start-up Time: ≤ 2 ms

Package Unit: 1000pcs/reel

Series: Oscillator SMD3225-M4
Type: VCTCXO-SMD3225-M4
Frequency: 19.200000 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 2.0 mA max.
Frequency Tolerance: ±1.5 ppm

Output Logic | Output Load: Clipped Sine Wave | 10kΩ / 10pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C

Absolute Pulling Range (APR): ±20 ppm min., ±30ppm max.
Control Voltage Range: 1.65V ±1.0V

Phase Noise at 12,80 MHz:
-90dBc/Hz at 10 Hz
-115dBc/Hz at 100 Hz
-128dBc/Hz at 1 kHz
-145dBc/Hz at 10 kHz
-149dBc/Hz at 100 kHz
-150dBc/Hz at 1 MHz

Start-up Time: ≤ 2 ms

Package Unit: 1000pcs/reel

Type: VCTCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave) | Non AKM IC

Frequency: 26.000000 MHz
Supply Voltage (VDD): +2.5 ±5%
Input Current: 1.5 mA max.

Frequency Stability vs Temperature Range: ±2.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.3 ppm max,
Frequency Stability Vs Load (±10%). ±0.3 ppm max.
Aging: ±1.0ppm max.

Control Voltage (Vcont): 1.5 V ±1.0 V DC
Frequency control range based on frequency at Vcont = +1.5 V DC:
... Min. +/-6.0 ppm
Frequency change polarity: Positive

Operating Temperature: -40°C to +85°C
Storage Temperature: -40°C to +85°C
Phase noise (typical):
... -85 dBc/Hz at 1 HZ offset
... -110 dBc/Hz at 10 Hz offset
... -133 dBc/Hz at 100 Hz offset
... -140 dBc/Hz at 1 kHz offset
... -145 dBc/Hz at 10 kHz offset
... -145 dBc/Hz at 100 kHz offset

RoHS: Pb free - 2011/65/EU (RoHS 2) compliant

Package Unit: 3000pcs/reel

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
Series: Oscillator SMD5032-M4 / QPS5
Type: VCTCXO-SMD5032-M4
Frequency: 25.000000 MHz
Supply Voltage (VDD): +2.4 ~ 5.5 VDC
Input Current: 1.5 mA max.
Frequency Tolerance: ±1.5 ppm
Supply voltage stability: ±0.2ppm, VDD ±5%
Load stability: ±0.2ppm, ZL ±10%
Ageing: ±1.0ppm max first year
Output Logic / Output Load: Clipped Sine Wave / 10kΩ// 10pF
Operating Temperature: -30°C to +75°C
Storage Temperature: -45°C to +85°C
Phase noise (typ @ 20.0MHz): -54dBc/Hz @ 1Hz -86dBc/Hz @ 10Hz -135dBc/Hz @ 1kHz -151dBc/Hz @ 100kHzStart-up Time: ≤ 2 ms
Package Unit: 1000pcs/reel

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
Series: Oscillator SMD5032-M4 / QPS5
Type: VCTCXO-SMD5032-M4
Frequency: 25.000000 MHz
Supply Voltage (VDD): +2.4 ~ 5.5 VDC
Input Current: 1.5 mA max.
Frequency Tolerance: ±1.5 ppm
Supply voltage stability: ±0.2ppm, VDD ±5%
Load stability: ±0.2ppm, ZL ±10%
Ageing: ±1.0ppm max first year
Output Logic / Output Load: Clipped Sine Wave / 10kΩ// 10pF
Operating Temperature: -30°C to +75°C
Storage Temperature: -45°C to +85°C
Phase noise (typ @ 20.0MHz): -54dBc/Hz @ 1Hz -86dBc/Hz @ 10Hz -135dBc/Hz @ 1kHz -151dBc/Hz @ 100kHzStart-up Time: ≤ 2 ms
Package Unit: 1000pcs/reel

'-
Manufacturer: Dow Enterprise Co., Ltd.
Series: UC533
Type: VCTCXO-SMD5032-M4
Frequency: 19.200000 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 1.5 mA max.
Frequency Tolerance at +25°C: ±2.0 ppm
Frequency Stability ...
... vs Temperature Range: ±1.5 ppm
... vs Supply Voltage (±5%): ±0.3 ppm
... vs Load (±5%): ±0.3 ppm
Aging: < ±1.0 ppm
Frequency adjustment: ±8ppm min, +1.5 ±1.0V
Ageing: ±1.0ppm max first year
Output Logic | Output Load: Clipped Sine Wave | 10kΩ / 10pF
Operating Temperature: -30°C to +75°C
Storage Temperature: -45°C to +85°C
Phase noise (typical):
... -80dBc/Hz@10Hz
... -105dBc/Hz@100 Hz
... -127dBc/Hz@1kHz
... -140dBc/Hz@10kHz
... -140dBc/Hz@100kHz
... -145dBc/Hz@1MHz
Start-up Time: ≤ 2 ms
Package Unit: 1000pcs/reel

'-
Manufacturer: Dow Enterprise Co., Ltd.
Series: UC533
Type: VCTCXO-SMD5032-M4
Frequency: 19.200000 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 1.5 mA max.
Frequency Tolerance at +25°C: ±2.0 ppm
Frequency Stability ...
... vs Temperature Range: ±2.5 ppm
... vs Supply Voltage (±5%): ±0.3 ppm
... vs Load (±5%): ±0.3 ppm
Aging: < ±1.0 ppm
Frequency adjustment: ±8ppm min, +1.5 ±1.0V
Ageing: ±1.0ppm max first year
Output Logic | Output Load: Clipped Sine Wave | 10kΩ / 10pF
Operating Temperature: -30°C to +75°C
Storage Temperature: -45°C to +85°C
Phase noise (typical):
... -80dBc/Hz@10Hz
... -105dBc/Hz@100 Hz
... -127dBc/Hz@1kHz
... -140dBc/Hz@10kHz
... -140dBc/Hz@100kHz
... -145dBc/Hz@1MHz
Start-up Time: ≤ 2 ms
Package Unit: 1000pcs/reel

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
-
Series: Oscillator SMD5032-M4 / QPS5
Type: VCTCXO-SMD5032-M4
Frequency: 25.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±10%
Input Current: 3.5 mA max.
Frequency Tolerance: ±2.5 ppm
Output Logic | Output Load: Clipped Sine Wave | 10kΩ / 10pF
Operating Temperature: -20°C to +70°C
Storage Temperature: -55°C to +125°C
Phase Noise at 12,80 MHz: -125dBc/Hz at 100 Hz, -145dBc/Hz at 1 kHz, -150dBc/Hz at 10 kHz
Start-up Time: ≤ 2 ms
-
Package Unit: 1000pcs/reel

UTECH Electronics Technology Co., Ltd.
Bauform: THT HC-49/U
Frequency: 16.000000 MHz
Mode: fund. AT
Load Capacitance: 30 pF
Tolerance at +25 °C: ±30 ppm
Tolerance over Temp.: ±50 ppm
Aging: ±3ppm max. 1 year
ESR max.: 25 Ohm
Operating Temp.: -20°C/+70°C

SUZHOU UTECH TECHNOLOGY CO.,LTD
QRS
TR250

UTECH Electronics Technology Co., Ltd.

Type: THT HC-49/U (h=13.5mm)
Frequency: 11.059200 MHz
Mode: fund. AT
Load Capacitance: 30 pF
Tolerance at +25 °C: ±30 ppm
Tolerance over Temp.: ±50 ppm
Aging: ±3ppm max. 1 year
ESR max.: 25 Ohm
Operating Temp.: -20°C/+70°C

Package Unit: 250 pcs/bag

'-
UTECH Electronics Technology Co., Ltd.
Type:                          THT HC-49/U
Frequency:                24.000000 MHz
Mode:                        fund. AT
Load Capacitance:    20 pF
Tolerance at +25 °C:  ±30 ppm
Tolerance over Temp.: ±30 ppm
Aging:                        ±3ppm max. 1 year
ESR max.:                  40 Ohm
Operating Temp.:       -20°C/+70°C

Bauform: HC-49/S
Frequency: 25,000000 MHz
Mode: fund.
Load Capacitance: 18 pF
Tolerance at +25 °C: ±10 ppm
Tolerance over Temp.: ±50 ppm
ESR max.: 20 Ohm
Operating Temp.: -20 / +70 °C

'-
UTECH, HC-49/S, 26,000000 MHz, fund. AT, CL: 16pF,
Tolerance at +25°C: ±10ppm, Tolerance over Temp.: ±15ppm,
Aging: max. 10 ppm aging over 11 years, “over all tolerance” = 35ppm max.,
ESR max.: 15 Ohm, Operating Temp.: -20/+70°C, bulk

'-
Type: THT HC-49S (QRDS)
Frequency: 12.000000 MHz
Mode: fund. AT
Load Capacitance: 30 pF
Tolerance at +25 °C: ±30 ppm
Tolerance over Temp.: ±30 ppm
Aging: ±3ppm max. 1 year
ESR max.: 70 Ohm
Operating Temp.: -20°C/+70°C
-
Package Unit: 250pcs/bag
-
# With Isolation Spacer #

'-
UTECH Electronics Technology Co., Ltd.
-
Type: THT HC-49S (QRDS)
Frequency: 13.560000 MHz
Mode: fund. AT
Load Capacitance: 30 pF
Tolerance at +25 °C: ±30 ppm
Tolerance over Temp.: ±30 ppm
Aging: ±3ppm max. 1 year
ESR max.: 40 Ohm
Operating Temp.: -20°C/+70°C
-
Package Unit: 250pcs/bag

UTECH Electronics Technology Co., Ltd.

Type: THT HC-49S (QRDS)
Frequency: 13.560000 MHz
Mode: fund. AT
Load Capacitance: 30.0 pF
Tolerance at +25 °C: ±30 ppm
Tolerance over Temp.: ±30 ppm
Aging: ±3ppm max. 1 year
ESR max.: 30 Ohm
Operating Temp.: -40°C/+85°C

Package Unit: 250 pcs/bag

'-
UTECH Electronics Technology Co., Ltd.
Type: THT HC-49/U
Frequency: 2.457600 MHz
Mode: fund. AT
Load Capacitance: 30 pF
Tolerance at +25 °C: ±30 ppm
Tolerance over Temp.: ±50 ppm
Aging: ±3ppm max. 1 year
ESR max.: 200 Ohm
Operating Temp.: -20°C/+70°C
