Produkte Suchen

Yoketan Corp.
SMD-Oscillator HCMOS - SO3225
TR3000

SUZHOU UTECH TECHNOLOGY CO.,LTD
Package Unit: 1000pcs/reel

'-
Epson P/N: Q3614CA00102700
Description: VG-4231CA 32.000000MHZ GRC-F
-
MOQ: 1000
Packing Unit 1000
-
Frequency: 32000
Actual Size (mm): 7.00X5.00X1.40
Voltage Supply: 3.3V
Output: CMOS

UTECH TECHNOLOGY CO.,LTD

Case Size: SMD7050-M2 (2PAD)
Frequency: 20.000000 MHz
Mode: fund. AT
Load Capacitance: 12.0 pF
Tolerance at +25 °C: ±50 ppm
Tolerance over Temp.: ±100 ppm
Aging max.: ±3 ppm / 1 year
ESR max.: 50 Ohm
Operating Temp.: -40°C/+105°C

Package Unit: 1000pcs/reel

Manufacturer: EPSON

Part Number: X1G004251002412
Description: SG3225EAN 100.000000MHZ KEGA
Packing unit: TR250L
Pb-free: Yes
Frequency: 100.000000 MHz
Frequency Tolerance: ±30 ppm
Output: LV-PECL
Actual Size (mm): 3.20 X 2.50 X 1.05
Stability: KEGA
Supply Voltage: 2.5~3.3V

'-
Manufacturer: EPSON
-
Part Number: X1G004251000614
Description: SG3225EAN 200.000000MHz KJGA
Packing: TR1000L (Pb free)
Packing unit: 1000
Pb-free: Yes
Frequency: 200 MHz
Frequency Tolerance: ±50 x 10-6
Output: LVDS
Actual Size: 3.2 x 2.5
Stability: KJGA
Supply Voltage: 2.5-3.3V
-
Related Items
X1G004251000600 (2000 in package)
X1G004251000601 (samples)
X1G004251000611
X1G004251000612 (250 in package)

Manufacturer: RIVER ELETEC CORPORATION


RIVER Ordering Code:
FCXO-04-200MHZ33SP8329-01

Package: 3000pcs/reel

--------------------------------------------------
Delivery Time: 90 to 120 days
--------------------------------------------------

Manufacturer: EPSON

Part Number: Q3806CA10003800
Description: EG-2102CA 106.250000MHZ +/-100PPM LHPA
Package: TR1000L

Manufacturer: EPSON

Part Number: Q3806CA10003400
Description: EG-2102CA 125.000000MHZ +/-100PPM LHRN
Package: TR1000L

'-
Manufacturer: ECS Inc. International您
-
ECXV-L32B1M-600.000
-
Series: Oscillator SMD2520-M6
Type: LVDS
Frequency: 600.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±10%
Frequency Tolerance: ±50 ppm
Output Logic / Output Load: LVDS
Operating Temperature: -20°C to +70°C
Storage Temperature: -55°C to +125°C
-
Package Unit: 1000pcs/reel

Manufacturer: Utech Electronics Technology Co., Ltd.

Series: Oscillator SMD3225-M6 | LVDS
Frequency: 100.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±10%
Input Current: 100 mA max

Frequency Stability Over All: : ±25 ppm
(Including at +25℃, Over Temperature Range, Supply Voltage Change, Shock
and Vibration, Aging 1st year)

Output Logic / Output Load: LVDS

Output Voltage VOL: 1.1V Typical
Output Voltage VOH: 1.4V Typical
Symmetry: 50%±5%
Rise / Fall Time: 1.5 ns max
Start-up Time: 10 ms max
Standby Current: 10µA max
Phase Jitter (rms): 1ps rms max 12kHz to 20MHz
Oscillation Mode: Overtone

Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C

Package Unit: 3000pcs/reel

'-
Manufacturer: EPSON
-
Part Number: X1G004241012414
Description: SG3225VAN 135.000000MHz KJGA
Packing: TR1000L (Pb free)
Packing unit: 1000
Pb-free: Yes
Frequency: 135 MHz
Frequency Tolerance: ±50 x 10-6
Output: LVDS
Actual Size: 3.2 x 3.2
Stability: KJGA
Supply Voltage: 2.5-3.3V
-
Related Items
X1G004241012400 (2000 in package)
X1G004241012401 (samples)
X1G004241012411
X1G004241012412 (250 in package)

Manufacturer: RIVER ELETEC CORPORATION

Part Number: FCXO-04
Description: LVDS
Actual Size: 3.2 x 2.5
Frequency: 135.000000 MHz
Frequency Tolerance: ±50 ppm
Output: LVDS
Operating Temperature: -40°C to +85°C
Supply Voltage: 3.3V

Package: 3000pcs/reel

EPSON

1+ €2.96298
250+ €1.18519
1000+ €0.98766
2000+ €0.89739
6000+ €0.81668
10000+ €0.76039
40000+ €0.72322

Manufacturer: Utech Electronics Technology Co., Ltd.

Series: Oscillator SMD5032-M6
Type: LVDS
Frequency: 100.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±10%
Frequency Tolerance: ±25 ppm
Output Logic / Output Load: LVDS
Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C

Package Unit: 1000pcs/reel

'-
UTECH, TCXO, SMD5032-M4, 22.000000 MHz, 3.3V, 2.5ppm, -30°C/+85°C

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
Series: Oscillator SMD5032-M6
Type: LVDS
Frequency: 160.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±10%
Frequency Tolerance: ±25 ppm
Output Logic / Output Load: CMOS / 15 pF
Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C
Package Unit: 1000pcs/reel

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
Series: Oscillator SMD5032-M6
Type: LVDS
Frequency: 160.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±10%
Frequency Tolerance: ±25 ppm
Output Logic / Output Load: CMOS / 15 pF
Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C
Package Unit: 1000pcs/reel

'-
Series: Oscillator SMD5032-M6
Type: LVDS
Frequency: 160.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±10%
Frequency Tolerance: ±50 ppm
Output Logic / Output Load: LVDS
Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C
-
Package Unit: 1000pcs/reel

Series: Oscillator SMD5032-M4 | KLO5
Type: TCXO-SMD5032-M6
Frequency: 94.000000 MHz
Supply Voltage (VDD): +1.8 VDC ±5%
Input Current: 35 mA max.
Frequency Tolerance: ±20 ppm max.
Output Load Condition: 100 Ohm (OUT - OUN)
Symmetry (Duty): 50% ±5%
Output rise and fall time ( Tr /Tf ): 600ps max (Output level 20% to 80%)
Output high level:1.43V Typ ~ 1.60V Max
Output low level: 0.90V Min ~ 1.10V Typ
Differential output voltage: 0.247V ~ 0.350V ~ 0.454V
Offset voltage: 1.125V ~ 1.250V ~ 1.375V

Pin 1 Function - Enable input voltage: 70% Vdd min or NC
Pin 1 Function - Disable input voltage: 30% Vdd max

Oscillation start up time: 5ms max
Aging (Initial first year): ± 3ppm max
Phase Jitter (12KHZ ~20MHZ): 0.3ps RMS max

Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C

Package Unit: 1000pcs/reel

'-
UTECH, TCXO, SMD5032-M4, 22.000000 MHz, 3.3V, 2.5ppm, -30°C/+85°C

'-
Manufacturer: UTECH TECHNOLOGY CO., LTD
Series: Oscillator SMD7050-M6
Type: LVDS
Frequency: 200.000000 MHz
Supply Voltage (VDD): +2.5 VDC ±5%
Frequency Tolerance: ±25 ppm
Output Logic / Output Load: LVDS / CMOS
E/D Funktion: YES (#1)
Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C
Package Unit: 100pcs/reel

'-
Manufacturer: KDK - KYUSHU DENTSU CO., LTD.
Series: Oscillator SMD7050-M6 / CEM22FT-L
Type: LVDS
Frequency: 200.000000 MHz
Supply Voltage (VDD): +2.5 VDC ±5%
Frequency Tolerance: ±25 ppm
Output Logic / Output Load: LVDS / CMOS
E/D Funktion: YES (#1)
Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C
Package Unit: 1000pcs/reel

Epson Product Code: Q3309CA40033400
Description: SG-8002CA 14.318180MHZ PC M
Actual Size (mm): 7.00 x 5.00 x 1.40

Min Order Quantity: 1000
Packing Unit: 1000

Seiko Epson Corporation
SG-8002CA 25.000000MHZ PC B
Q3309CA40010812
250pcs/reel

Seiko Epson Corporation
SG-8002CA 48.000000MHZ PH C
Q3309CA20001700
TR1000

'-
Manufacturer: Epson Electronics
-
Epson Part No.: Q3204DC31003200
-
Typ: SMD-Oscillator SG-8002DC 80.000000MHz PT C

Case size: SMD 13.7 x 6.6 mm
Frequency: 80.000000 MHz
Power Supply Voltage: 4.5 ~ 5.5 Volt
Frequency Stability: ±100 ppm
Operating Temp.: -20°C/+70°C
-
Packing: TUBE (Pb free)

'-
Manufacturer: Epson Electronics
-
Epson Part No.: Q3321CE40004214
-
Typ: SMD-OscillatorSG-8002CE 12.000000MHz PC C

Case size: SMD 3.2 x 2.5 x 1.00 mm
Frequency: 12.000000 MHz
Power Supply Voltage: 2.7~3.6 Volt
Frequency Stability: ±100 ppm
Operating Temp.: -20°C/+70°C
-
Packing: 1000pcs/reel
.

'-
Manufacturer: Epson Electronics
-
Epson Part No.: Q3204DC31003200
-
Typ: SMD-Oscillator SG-8002DC 80.000000MHz PT C

Case size: SMD 13.7 x 6.6 mm
Frequency: 80.000000 MHz
Power Supply Voltage: 4.5 ~ 5.5 Volt
Frequency Stability: ±100 ppm
Operating Temp.: -20°C/+70°C
-
Packing: TUBE (Pb free)

EPSON PRODUCT CODE: Q3307JC41079700
DESCRIPTION: SG-8002JC 11.059200MHZ PC C
ACTUAL SIZE(MM): 10.50X5.80X2.70

MIN ORDER QUANTITY: 1000
PACKING UNIT: 1000

LEAD TIME: 10 TO 14 WEEKS
