Utech Electronics Technology Co., Ltd.
-
Frequency: 26.000000 MHz
Oscillation Mode: Fundamental
Supply Voltage (VCC): 2.8V ±5%
Input Current: 1.5 mA max
Output Level Clipped Sine(Vp-p): 0.8V min
Harmonics: -5 dBc max
Frequency Tolerance After Reflow (at +25°C): ±2 ppm max
Frequency Stability Vs Temperature Range: ±2 ppm max
Operating Temperature Range: -40~+85°C
Temperature slope @-20~+70°C: ±0.1 ppm / °C
Temperature slope @-40~+85°C: ±0.3 ppm / °C
Storage Temperature Range: -40~+85°C
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm
Frequency Stability Vs Load (±10%): ±0.2 ppm
Output Waveform: Clipped Sine wave
Output Load: 10 KΩ // 10 pF
Start-up Time Vs frequency: ≤ 2.0 ms / within ±1 ppm
Aging : ±1 ppm max first year
-
Package Unit: 3000pcs/reel

Utech Electronics Technology Co., Ltd.

Frequency: 26.000000 MHz
Oscillation Mode: Fundamental
Supply Voltage (VCC): 1.8V to 3.3V
Input Current: 1.5 mA max
Output Level Clipped Sine(Vp-p): 0.8V min
Harmonics: -5 dBc max
Frequency Tolerance After Reflow (at +25°C): ±2 ppm max
Frequency Stability Vs Temperature Range: ±2 ppm max
Operating Temperature Range: -40~+85°C
Temperature slope @-20~+70°C: ±0.1 ppm / °C
Temperature slope @-40~+85°C: ±0.3 ppm / °C
Storage Temperature Range: -40~+85°C
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm
Frequency Stability Vs Load (±10%): ±0.2 ppm
Output Waveform: Clipped Sine wave
Output Load: 10 KΩ // 10 pF
Start-up Time Vs frequency: ≤ 2.0 ms / within ±1 ppm
Aging : ±1 ppm max first year

Package Unit: 3000pcs/reel

Manufacturer: UTECH TECHNOLOGY CO.,LTD

Type: TCXO-SMD2520-M4 - CSW Output (Clipped Sine Wave)

Case Size: 2.5 x 2.0 x 0.90 mm

Frequency: 32.000000 MHz
Supply Voltage (VDD): +1.8 ~ +3.3V
Input Current: 2.0 mA max.

Frequency Tolerance After Reflow at +25°C: ±1.0 ppm max.
Frequency Stability
... vs Temperature Range: ±0.5 ppm max.
... vs Supply Voltage (±5%): ±0.3 ppm max,
... vs Load (±5%). ±0.3 ppm max.
Aging: ±1.0ppm max.

Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C

RoHS: Pb free - 2011/65/EU (RoHS 2) compliant

Package Unit: 3000pcs/reel

'-
Utech Electronics Technology Co., Ltd.
-
Frequency: 36.000000 MHz
Oscillation Mode: Fundamental
Supply Voltage (VCC): 3.3V
Frequency Stability Vs Temperature Range: ±1.0 ppm max
Operating Temperature Range: -40~+85°C
Storage Temperature Range: -40~+85°C
Output Waveform: Clipped Sine wave
Aging : ±1 ppm max first year, ±5ppm max after 15 years
Phase Noise typ.:
... -130 dBc / Hz at +- ≥1 kHz
... -140 dBc / Hz at +- ≥10 kHz
... -150 dBc / Hz at +- ≥50 kHz
... -150 dBc / Hz at +- ≥100 kHz
-
Package Unit: 3000pcs/reel

SUZHOU UTECH TECHNOLOGY CO.,LTD
TR3000

Utech Electronics Technology Co., Ltd.

Frequency: 38.400000 MHz
Oscillation Mode: Fundamental
Supply Voltage (VCC): 3.3V ±5%

Initial Frequency Tolerance @+25°C±2°C at time of shipment: ±1.0ppm
... Reflow Shift: ±1.0ppm
... Frequency Stability over Operating Temperature Range: ±0.5ppm
... Sensitivity vs. Supply Voltage Variations (Vdd±5% @ +25°C): ±0.1ppm
... Sensitivity vs. Load Variations (±10% load change @ +25°C); ±0.2ppm
... Long Term Stability (frequency drift over 1 year @ +25°C): ±1.0ppm

Operating Temperature Range: -40~+85°C
Storage Temperature Range: -40~+85°C
Output Waveform: Clipped Sine wave

Startup Time (amplitude): 0.5ms
Startup Time (frequency): 2 ms


Phase Noise typ.:
... -130 dBc / Hz at +- ≥1 kHz
... -140 dBc / Hz at +- ≥10 kHz
... -150 dBc / Hz at +- ≥50 kHz
... -150 dBc / Hz at +- ≥100 kHz

Package Unit: 3000pcs/reel

'-
Series: Oscillator SMD2520-M4
Type: TCXO - CMOS Output
Frequency: 40.000000 MHz
Supply Voltage (VDD): +2.8 VDC ±10%
Input Current: 5.2 mA max.
Frequency Tolerance: ±2.0 ppm
Output Logic / Output Load: CMOS / 15 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -55°C to +125°C
Phase Noise at:-145dBc/Hz at 10 kHz
Start-up Time: ≤ 10 ms
Package Unit: 3000pcs/reel

'-
Series: Oscillator SMD2520-M4
Type: TCXO - CMOS Output
Frequency: 40.000000 MHz
Supply Voltage (VDD): +2.8 VDC ±10%
Input Current: 5.2 mA max.
Frequency Tolerance: ±2.0 ppm
Output Logic / Output Load: CMOS / 15 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -55°C to +125°C
Phase Noise at:-145dBc/Hz at 10 kHz
Start-up Time: ≤ 10 ms
Package Unit: 3000pcs/reel

Utech Electronics Technology Co., Ltd.

Frequency: 50.000000 MHz
Oscillation Mode: Fundamental
Supply Voltage (VCC): 1.8V ~ 3.3V
Input Current: 2.0 mA max
Output Level Clipped Sine(Vp-p): 0.8 Vp-p min
Harmonics: -5 dBc max

Frequency Tolerance After Reflow (at +25℃): ±2.0 ppm max
Frequency Stability Vs Temperature Range: ±2.0 ppm max

Operating Temperature Range: -40°C ~ +85°C
Storage Temperature Range: -55°C ~ +125°C

Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm max
Frequency Stability Vs Load (±10%): ±0.2 ppm max
Output Waveform: Clipped Sine wave
Output Load: 10 KΩ // 10 pF
Start-up Time Vs frequency: 2.0 ms max within ±1.0 ppm
Aging: ±1.0 ppm/year max

Phase Noise typ.:
10Hz Offset -70 dBc/Hz
100Hz Offset -105 dBc/Hz
1KHz Offset -125 dBc/Hz
10KHz Offset -145 dBc/Hz

Package Unit: 3000pcs/reel

Utech Electronics Technology Co., Ltd.

Frequency: 50.000000 MHz
Oscillation Mode: Fundamental
Supply Voltage (VCC): 1.8V ~ 3.3V
Input Current: 2.0 mA max
Output Level Clipped Sine(Vp-p): 0.8 Vp-p min
Harmonics: -5 dBc max

Frequency Tolerance After Reflow (at +25℃): ±2.0 ppm max
Frequency Stability Vs Temperature Range: ±2.0 ppm max

Operating Temperature Range: -40°C ~ +85°C
Storage Temperature Range: -55°C ~ +125°C

Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm max
Frequency Stability Vs Load (±10%): ±0.2 ppm max
Output Waveform: Clipped Sine wave
Output Load: 10 KΩ // 10 pF
Start-up Time Vs frequency: 2.0 ms max within ±1.0 ppm
Aging: ±1.0 ppm/year max

Phase Noise typ.:
10Hz Offset -70 dBc/Hz
100Hz Offset -105 dBc/Hz
1KHz Offset -125 dBc/Hz
10KHz Offset -145 dBc/Hz

Package Unit: 3000pcs/reel

Manufacturer: UTECH TECHNOLOGY CO.,LTD

Type: TCXO-SMD2520-M4 - CMOS | QPS2

Frequency: 8.000000 MHz
Supply Voltage (VDD): 3.3V ±5%.
Input Current: 6.0 mA max.
Operating Temperature Range: -40°C～+105℃
Storage Temperature Range: -55～+125°C
Output Waveform: CMOS
Output Load: 10 KΩ // 15 pF
RoHS: Pb free - 2011/65/EU (RoHS 2) compliant

Package Unit: 3000pcs/reel

'-
Type: TCXO-SMD2520-M6 - CSW Output (Clipped Sine Wave) | AKM IC
-
Frequency: 26.000000 MHz
Supply Voltage (VDD): +1.8, +2.8V, +3.0V ±5%
Input Current: 1.5 mA max.
-
Frequency Stability vs Temperature Range -30/+85°C: ±0.5 ppm max.
Frequency Stability vs Temperature Range -40/+85°C: ±3.0 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.1 ppm max,
Frequency Stability Vs Load (±10%). ±0.1 ppm max.
Aging: ±0.7ppm max. 1st Year
Aging: ±1.4ppm max. 2nd Year
Aging: ±2.5ppm max. 5th Year
Aging: ±5.0ppm max. 10th Year
-
Operating Temperature: -40°C to +85°C
Storage Temperature: -40°C to +85°C
Phase noise (typical):
... -50dBc/Hz at 1 Hz offset
... -73dBc/Hz at 5 Hz offset
... -80dBc/Hz at 10 Hz offset
... -106dBc/Hz at 100 Hz offset
... -134dBc/Hz at 1 kHz offset
... -144dBc/Hz at 10 kHz offset
... -152dBc/Hz at 100 kHz offset
-
RoHS: Pb free - 2011/65/EU (RoHS 2) compliant
-
Package Unit: 3000pcs/reel

'-
Type: TCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave)
-
Frequency: 14.745600 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 1.5 mA max.
-
Frequency Stability vs Temperature Range: ±2.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm max,
Frequency Stability Vs Load (±10%). ±0.2 ppm max.
Aging: ±1.0ppm max.
-
Output Logic / Output Load: Clipped Sine Wave / 10 kOhm, 10 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C
Phase noise (typical): -135dBc/Hz at 1kHz offset
Start-up Time: ≤ 2 ms
-
RoHS: Pb free - 2011/65/EU (RoHS 2) compliant
-
Package Unit: 1000pcs/reel

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
-
Type: TCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave)
-
Frequency: 14.745600 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 1.5 mA max.
-
Frequency Stability vs Temperature Range: ±2.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm max,
Frequency Stability Vs Load (±10%). ±0.2 ppm max.
Aging: ±1.0ppm max.
-
Output Logic / Output Load: Clipped Sine Wave / 10 kOhm, 10 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C
Phase noise (typical): -135dBc/Hz at 1kHz offset
Start-up Time: ≤ 2 ms
Package Unit: 1000pcs/reel

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
-
Type: TCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave)
-
Frequency: 14.745600 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 1.5 mA max.
-
Frequency Stability vs Temperature Range: ±2.5 ppm max. over -30°C ~+85°C
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm max,
Frequency Stability Vs Load (±10%). ±0.2 ppm max.
Aging: ±1.0ppm max./year
-
phase noise max.:
-80 dBc/Hz at 10 Hz
-110 dBc/Hz at 100 Hz
-130 dBc/Hz at 1 kHz
-145 dBc/Hz at 10 kHz
-150 dBc/Hz at 100 kHz
-150 dBc/Hz at 1 MHz
-
Output Logic / Output Load: Clipped Sine Wave / 10 kOhm, 10 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C
Start-up Time: ≤ 2 ms
-
Package Unit: 1000pcs/reel

Type: TCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave) | Non AKM IC

Frequency: 25.000000 MHz
Supply Voltage (VDD): +3.3 ±5%
Input Current: 2.0 mA max.

Frequency Stability vs Temperature Range: ±2.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.3 ppm max,
Frequency Stability Vs Load (±10%). ±0.3 ppm max.
Aging: ±1.0ppm max.

Operating Temperature: -40°C to +85°C
Storage Temperature: -40°C to +85°C
Phase noise (typical):
... -80dBc/Hz at 10 Hz offset
... -110dBc/Hz at 100 Hz offset
... -130dBc/Hz at 1 kHz offset
... -140dBc/Hz at 10 kHz offset
... -140dBc/Hz at 100 kHz offset
... -145dBc/Hz at 1 MHz offset

RoHS: Pb free - 2011/65/EU (RoHS 2) compliant

Package Unit: 3000pcs/reel

Type: TCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave)

Frequency: 26.000000 MHz
Supply Voltage (VDD): +2.8 ±5%
Input Current: 2.0 mA max.

Frequency Stability vs Temperature Range: ±2.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.3 ppm max,
Frequency Stability Vs Load (±10%). ±0.3 ppm max.
Aging: ±1.0ppm max.

Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C

Phase noise (typical):
... -80 dBc/Hz at 10 Hz offset
... -110 dBc/Hz at 100 Hz offset
... -130 dBc/Hz at 1k Hz offset
... -140 dBc/Hz at 10 kHz offset
... -145 dBc/Hz at 100 kHz offset

Start-up Time: ≤ 2 ms

RoHS: Pb free - 2011/65/EU (RoHS 2) compliant

Package Unit: 1000pcs/reel

'-
Type: TCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave) | Non AKM IC
-
Frequency: 26.000000 MHz
Supply Voltage (VDD): +2.8 ±5%
Input Current: 2.0 mA max.
-
Frequency Stability vs Temperature Range: ±2.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.3 ppm max,
Frequency Stability Vs Load (±10%). ±0.3 ppm max.
Aging: ±1.0ppm max.
-
Operating Temperature: -40°C to +85°C
Storage Temperature: -40°C to +85°C
Phase noise (typical):
... -80dBc/Hz at 10 Hz offset
... -110dBc/Hz at 100 Hz offset
... -130dBc/Hz at 1 kHz offset
... -140dBc/Hz at 10 kHz offset
... -140dBc/Hz at 100 kHz offset
... -145dBc/Hz at 1 MHz offset
-
RoHS: Pb free - 2011/65/EU (RoHS 2) compliant
-
Package Unit: 3000pcs/reel

Type: TCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave) | Non AKM IC

Frequency: 26.000000 MHz
Supply Voltage (VDD): +3.3 ±5%
Input Current: 2.0 mA max.
-
Frequency Stability vs Temperature Range: ±2.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.3 ppm max,
Frequency Stability Vs Load (±10%). ±0.3 ppm max.
Aging: ±1.0ppm max.

Operating Temperature: -40°C to +85°C
Storage Temperature: -40°C to +85°C
Phase noise (typical):
... -80dBc/Hz at 10 Hz offset
... -110dBc/Hz at 100 Hz offset
... -130dBc/Hz at 1 kHz offset
... -140dBc/Hz at 10 kHz offset
... -140dBc/Hz at 100 kHz offset
... -145dBc/Hz at 1 MHz offset

RoHS: Pb free - 2011/65/EU (RoHS 2) compliant

Package Unit: 3000pcs/reel

Type: TCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave)

Frequency: 32.000000 MHz
Supply Voltage (VDD): +3.3 ±5%
Input Current: 2.0 mA max.

Frequency Stability vs Temperature Range: ±0.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.3 ppm max,
Frequency Stability Vs Load (±5%). ±0.3 ppm max.
Aging: ±1.0ppm max.

Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C

RoHS: Pb free - 2011/65/EU (RoHS 2) compliant

Package Unit: 3000pcs/reel

Type: TCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave)

Frequency: 32.000000 MHz
Supply Voltage (VDD): +3.3 ±5%
Input Current: 2.0 mA max.

Frequency Stability vs Temperature Range: ±1.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm max,
Frequency Stability Vs Load (±5%). ±0.3 ppm max.
Aging: ±1.0ppm max.

Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C

Phase noise (typical):
... -80 dBc/Hz at 10 Hz offset
... -110 dBc/Hz at 100 Hz offset
... -130 dBc/Hz at 1 kHz offset
... -140dBc/Hz at 10 kHz offset
... -140dBc/Hz at 100 kHz offset
... -145dBc/Hz at 1 MHz offset

RoHS: Pb free - 2011/65/EU (RoHS 2) compliant

Package Unit: 3000pcs/reel

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
-
Series: Oscillator SMD5032-M4 / QPS5
Type: TCXO-SMD5032-M4
Frequency: 16.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±10%
Input Current: 6 mA max.
Frequency Tolerance: ±2.5 ppm
Output Logic / Output Load: Clipped Sine Wave / 10kΩ// 10pF
Operating Temperature: -20°C to +70°C
Storage Temperature: -55°C to +125°C
Phase Noise at 12,80 MHz: -125dBc/Hz at 100 Hz, -145dBc/Hz at 1 kHz, -150dBc/Hz at 10 kHz
Start-up Time: ≤ 2 ms
-
Package Unit: 1000pcs/reel

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
Series: Oscillator SMD5032-M4
Type: TCXO-SMD5032-M4
Frequency: 20.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±10%
Input Current: 6 mA max.
Frequency Tolerance: ±2.5 ppm
Output Logic / Output Load: CMOS / 15 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -55°C to +125°C
Phase Noise at 12,80 MHz: -125dBc/Hz at 100 Hz, -145dBc/Hz at 1 kHz, -150dBc/Hz at 10 kHz
Start-up Time: ≤ 2 ms
Package Unit: 1000pcs/reel

'-
UTECH, TCXO, SMD5032-M4, 22.000000 MHz, 3.3V, 2.5ppm, -30°C/+85°C

'-
Series: Oscillator SMD2520-M4
Type: TCXO - CMOS Output
Frequency: 40.000000 MHz
Supply Voltage (VDD): +2.8 VDC ±10%
Input Current: 5.2 mA max.
Frequency Tolerance: ±2.0 ppm
Output Logic / Output Load: CMOS / 15 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -55°C to +125°C
Phase Noise at:-145dBc/Hz at 10 kHz
Start-up Time: ≤ 10 ms
Package Unit: 3000pcs/reel

Type: TCXO-SMD7050-M4 - CSW Output (Clipped Sine Wave)

Frequency: 14.745600 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 2 mA max.

Frequency Stability vs Temperature Range: ±2.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.3 ppm max,
Frequency Stability Vs Load (±10%). ±0.3 ppm max.
Aging: ±1.0ppm max.

Output Logic / Output Load: CSW Clipped Sine Wave / 10 kOhm, 10 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C
Phase noise (typical): -130dBc/Hz at 1kHz offset
Start-up Time: ≤ 2 ms
Package Unit: 500pcs/reel

Type: TCXO-SMD7050-M4 - CSW Output (Clipped Sine Wave) | PT75P-3C253F

Frequency: 14.745600 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 3 mA max.

Frequency Stability vs Tolerance at +25°C: ±1.0 ppm max.
Frequency Stability vs Temperature Range: ±2.5 ppm max.
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm max,
Frequency Stability Vs Load (±10%). ±0.2 ppm max.
Aging: ±1.0ppm max.

Output Logic / Output Load: CSW Clipped Sine Wave / 10 kOhm, 10 pF
Output Level: 0.8 V p-p min
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C
Phase noise (typical): -135dBc/Hz at 1kHz offset
Start-up Time: ≤ 2 ms
Package Unit: 500pcs/reel

'-
UTECH, TCXO, SMD5032-M4, 22.000000 MHz, 3.3V, 2.5ppm, -30°C/+85°C

Manufacturer: Utech Electronics Technology Co., Ltd.

Type: Oscillator VCTCXO-SMD2016-M4
Frequency: 39.000000 MHz
Supply Voltage (VDD): +2.8 VDC ±5%
Input Current: 1.8 mA max.

Frequency Tolerance: ±2.7 ppm
... Frequency tolerance: ±1.5 ppm @+25°C
... Frequency/temperature characteristics: ±1.0 ppm
... Frequency/load coefficient: ±0.1 ppm
... Frequency/voltage coefficient: ±0.1 ppm
... Frequency aging: ±1.0 ppm

Frequency control range: ±8.0 ppm to ± 12.0 ppm at VC =1.4V±1.0V (VCC =2.8V)

Output Logic | Output Load: Clipped Sine Wave | 10kΩ / 10pF ±10%
Operating Temperature: -40°C to +85°C
Storage Temperature: -40°C to +90°C

Start-up Time: ≤ 1 ms

Package Unit: 1000pcs/reel

EPSON
X1G005441031612
TG2016SMN 48.000000MHZ MCGNNM

Case Size: Oscillator SMD2016-M4 (2.0 × 1.6 × 0.73 mm)
Series: TG2016SMN
Type: VCTCXO - CSW Output (Clipped Sine Wave)
Frequency: 48.000000 MHz
Supply Voltage (VDD): +2.8 ~ +3.3 VDC
Input Current: 2.0 mA max.
Frequency Tolerance (at +25°C): ±1.5 ppm
Frequency Stability vs Temperature Range: ±0.5 ppm
Frequency Stability Vs Supply Voltage (±5%): ±0.1 ppm
Frequency Stability Vs Load (±10%). ±0.1 ppm
Frequency control range: ±8.0 ppm to ±12.0 ppm
Symmetry: 50%±5%
Aging max.: ±1.5ppm
Output Logic / Output Load: CSW - Clipped Sine Wave
Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C
Start-up Time: ≤ 2 ms

Package Unit: 250 pcs/reel
