[40-0024] O-TCXO-SMD2520-M4-24.000000 MHz-1.8~3.3-2.0-4085-CSW
'-
Utech Electronics Technology Co., Ltd.
-
Frequency: 24.000000 MHz
Oscillation Mode: Fundamental
Supply Voltage (VCC): 1.8V to 3.3V
Input Current: 1.5 mA max
Output Level Clipped Sine(Vp-p): 0.8V min
Harmonics: -5 dBc max
Frequency Tolerance After Reflow (at +25°C): ±2 ppm max
Frequency Stability Vs Temperature Range: ±2 ppm max
Operating Temperature Range: -40~+85°C
Temperature slope @-20~+70°C: ±0.1 ppm / °C
Temperature slope @-40~+85°C: ±0.3 ppm / °C
Storage Temperature Range: -40~+85°C
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm
Frequency Stability Vs Load (±10%): ±0.2 ppm
Output Waveform: Clipped Sine wave
Output Load: 10 KΩ // 10 pF
Start-up Time Vs frequency: ≤ 2.0 ms / within ±1 ppm
Aging : ±1 ppm max first year
-
Package Unit: 3000pcs/reel
Spezifikationen
| OSCILLATOR | |
|---|---|
| O 3.01 Nominal Frequency (Fo) | 24.000000 MHz |
| O 3.02 Supply Voltage (VDD) | 1.8 ~ 3.3 V |
| O 3.03 Input Current | 1.5 mA |
| O 3.04 Frequency Stability Over All * | 2 |
| O 3.05 Operating Temp. Range | -40°C ~ +85°C |
| O 3.07 Output Logic | - |
| O 3.08 Output Load | 10 pF |
| O 3.09 “1” Level | - |
| O 3.10 “0” Level | Voltage (VCC): 1.8C to 3.3V |
| O 3.12 Symmetry | - |
| O 3.13 Rise / Fall Time | - |
| O 3.14 Output Disable / Enable Delay Time | - |
| O 3.15 Start-up Time | Start-up Time Vs frequency: ≤ 2.0 ms / within ±1 ppm |
