10-0001 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.05 |
12.000000 MHz |
10pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0001 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.05 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0002 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
10pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0002 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0003 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
12pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0003 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0004 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
12pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0004 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0005 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
12pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0005 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0006 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
12pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0006 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0007 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0007 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0008 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0008 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0009 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0009 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0010 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
10pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0010 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0011 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0011 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0012 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
12pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0012 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0013 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
12pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0013 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0014 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
12pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0014 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0015 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
16pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0015 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0016 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
16pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0016 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0017 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
16pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0017 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100 µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0018 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
18pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0018 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0019 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
18pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0019 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0020 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000 MHz |
18pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0020 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0021 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000 MHz |
18pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0021 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0022 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000 MHz |
20pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0022 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0023 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000 MHz |
20pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0023 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0024 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000 MHz |
20pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0024 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0025 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0025 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0026 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000 MHz |
12pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0026 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0027 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0027 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0028 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0028 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0029 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000 MHz |
18pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0029 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0030 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000 MHz |
18pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0030 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0031 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000000 MHz |
10pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0031 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0032 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000000 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0032 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0033 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0033 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0034 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000000 MHz |
16pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0034 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0035 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000000 MHz |
16pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0035 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0644 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000000 MHz |
9pF |
±50ppm |
±50ppm |
-40°C to +125°C |
| Part-Number: | 10-0644 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 9pF |
| Frequency Tolerance at 25°C: | ±50ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +125°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0037 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000000 MHz |
10pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0037 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0038 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000000 MHz |
10pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0038 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0039 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000000 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0039 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0040 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000000 MHz |
12pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0040 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0041 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
12pF |
±20ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0041 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0042 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
12pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0042 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0043 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
16pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0043 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0044 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
16pF |
±25ppm |
±25ppm |
-20°C to +70°C |
| Part-Number: | 10-0044 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±25ppm |
| Frequency Tolerance over Temperature: | ±25ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0045 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0045 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0046 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120 MHz |
12pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0046 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0047 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120 MHz |
12pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0047 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0048 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120 MHz |
16pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0048 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0049 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0049 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0050 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
30.000 MHz |
8pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0050 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 30.000 MHz |
| Load Capacitance CL: | 8pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0051 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
30.000000 MHz |
8pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0051 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 30.000000 MHz |
| Load Capacitance CL: | 8pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0052 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
30.000000 MHz |
10pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0052 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 30.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0053 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
30.000000 MHz |
10pF |
±10ppm |
±20ppm |
-20°C to +70°C |
| Part-Number: | 10-0053 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 30.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0054 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
30.000000 MHz |
10pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0054 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 30.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0055 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
30.000000 MHz |
12pF |
±10ppm |
±5ppm |
-20°C to +70°C |
| Part-Number: | 10-0055 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 30.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±5ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0056 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
30.000000 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0056 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 30.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0057 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432000 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0057 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0058 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0058 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0059 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432000 MHz |
16pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0059 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0060 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0060 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0061 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432 MHz |
18pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0061 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0062 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432 MHz |
18pF |
±20ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0062 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0063 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0063 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0064 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560 MHz |
12pF |
±15ppm |
±20ppm |
-20°C to +70°C |
| Part-Number: | 10-0064 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±15ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0065 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560 MHz |
12pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0065 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0066 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0066 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0067 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0067 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0068 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
40.000 MHz |
10pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0068 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 40.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | ±20ppm max. for 10 years |
|
|
|
|
10-0069 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
40.000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0069 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 40.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0070 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
40.000000 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0070 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 40.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0071 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
40.000000 MHz |
20pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0071 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 40.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0072 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
40.000000 MHz |
20pF |
±10ppm |
±9ppm |
-20°C to +70°C |
| Part-Number: | 10-0072 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 40.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±9ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±2 ppm max. |
|
|
|
|
10-0073 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.745600 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0073 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0074 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.745600 MHz |
12pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0074 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0075 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.745600 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0075 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0076 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.745600 MHz |
16pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0076 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0077 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000000 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0077 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0078 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000000 MHz |
12pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0078 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0079 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0079 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0080 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000000 MHz |
6.5pF |
±25ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0080 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000000 MHz |
| Load Capacitance CL: | 6.5pF |
| Frequency Tolerance at 25°C: | ±25ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | ±1ppm max 1 year, 15ppm max over 11 years |
|
|
|
|
10-0081 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000 MHz |
10pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0081 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0082 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000 MHz |
10pF |
±10ppm |
±20ppm |
-20°C to +70°C |
| Part-Number: | 10-0082 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0083 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000000 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0083 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0084 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0084 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0085 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000 MHz |
16pF |
±10ppm |
±20ppm |
-20°C to +70°C |
| Part-Number: | 10-0085 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0086 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000 MHz |
16pF |
±20ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0086 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0087 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000 MHz |
18pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0087 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0088 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
19.3536 MHz |
10pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0088 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 19.3536 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0089 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
19.3536 MHz |
10pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0089 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 19.3536 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0090 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.576000 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0090 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.576000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0091 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.576000 MHz |
12pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0091 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.576000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0092 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.576000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0092 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.576000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0093 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.576000 MHz |
16pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0093 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.576000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0094 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.576000 MHz |
18pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0094 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.576000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0095 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.576000 MHz |
18pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0095 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.576000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0096 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
48.000000 MHz |
10pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0096 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 48.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0097 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
48.000000 MHz |
10pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0097 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 48.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0098 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
48.000000 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0098 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 48.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0099 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
48.000000 MHz |
12pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0099 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 48.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0100 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
48.000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0100 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 48.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0101 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
48.000 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0101 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 48.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0102 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0102 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0103 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000 MHz |
12pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0103 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0104 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0104 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0105 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0105 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0106 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
19.6608 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0106 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 19.6608 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0107 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
19.6608 MHz |
12pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0107 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 19.6608 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0108 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
48.012 MHz |
12pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0108 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 48.012 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0109 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.000 MHz |
6pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0109 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.000 MHz |
| Load Capacitance CL: | 6pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0110 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
39.000000 MHz |
8pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0110 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 39.000000 MHz |
| Load Capacitance CL: | 8pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0111 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
11.059200 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0111 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 11.059200 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0112 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
11.059200 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0112 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 11.059200 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0113 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.575625 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0113 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.575625 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0114 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.560000 MHz |
12pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0114 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.560000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0115 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.560000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0115 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.560000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0116 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.560000 MHz |
16pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0116 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.560000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0117 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
10.368000 MHz |
15pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0117 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 10.368000 MHz |
| Load Capacitance CL: | 15pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 250 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0118 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.288000 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0118 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.288000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0119 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.288000 MHz |
12pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0119 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.288000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0120 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.500 MHz |
20pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0120 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.500 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 560pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0122 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.7456 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0122 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.7456 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0123 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.31818 MHz |
12pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0123 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.31818 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0124 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.31818 MHz |
12pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0124 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.31818 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0125 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
33.300 MHz |
12pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0125 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 33.300 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0126 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
33.300 MHz |
12pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0126 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 33.300 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0127 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
19.200 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0127 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 19.200 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0128 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000 MHz |
10pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0128 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0129 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000 MHz |
12pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0129 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0130 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000 MHz |
16pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0130 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0131 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
16pF |
±10ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0131 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0132 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
16pF |
±10ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0132 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0133 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
18pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0133 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0134 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
18pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0134 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0135 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
18pF |
±10ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0135 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0136 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
20pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0136 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0137 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
20pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0137 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0138 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000000 MHz |
7pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0138 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 7pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0139 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000000 MHz |
8pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0139 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 8pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0140 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000000 MHz |
9pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0140 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 9pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0141 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
10pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0141 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0142 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
10pF |
±50ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0142 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±50ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0143 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
12pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0143 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0144 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
12pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0144 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0145 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
16pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0145 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0146 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
16pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0146 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0147 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0147 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0148 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
16pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0148 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0149 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
18pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0149 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0150 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
18pF |
±20ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0150 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0151 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000000 MHz |
18pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0151 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0152 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000000 MHz |
20pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0152 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0153 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000000 MHz |
8pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0153 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 8pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0154 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000000 MHz |
12pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0154 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0155 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000000 MHz |
12pF |
±20ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0155 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0156 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000000 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0156 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0157 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000000 MHz |
12pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0157 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0158 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000000 MHz |
12pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0158 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0159 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000000 MHz |
16pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0159 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0160 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000000 MHz |
16pF |
±10ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0160 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0161 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000 MHz |
18pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0161 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0162 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000 MHz |
18pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0162 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0163 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000 MHz |
20pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0163 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0164 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000 MHz |
20pF |
±50ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0164 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±50ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0165 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.31818 MHz |
12pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0165 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.31818 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0166 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.31818 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0166 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.31818 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0167 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.31818 MHz |
12pF |
±30ppm |
±10ppm |
-40°C to +85°C |
| Part-Number: | 10-0167 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.31818 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0168 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.31818 MHz |
16pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0168 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.31818 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0169 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.31818 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0169 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.31818 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0170 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.318180 MHz |
16pF |
±10ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0170 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.318180 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0171 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
10pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0171 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0172 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
10pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0172 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0173 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
12pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0173 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0174 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
12pF |
±10ppm |
±10ppm |
-40°C to +85°C |
| Part-Number: | 10-0174 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0175 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
12pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0175 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0176 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
12pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0176 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±2 ppm max. |
|
|
|
|
10-0177 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
12pF |
±10ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0177 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0178 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
12pF |
±10ppm |
±150ppm |
-40°C to +85°C |
| Part-Number: | 10-0178 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±150ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0181 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432000 MHz |
12pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0181 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0182 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432 MHz |
12pF |
±10ppm |
±10ppm |
-40°C to +85°C |
| Part-Number: | 10-0182 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0183 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432 MHz |
12pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0183 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0184 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432 MHz |
12pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0184 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0185 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432 MHz |
16pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0185 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0186 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432 MHz |
16pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0186 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0187 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432 MHz |
18pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0187 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0188 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432 MHz |
18pF |
±20ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0188 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0189 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.576 MHz |
12pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0189 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.576 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0190 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.576000 MHz |
12pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0190 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.576000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0191 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.576000 MHz |
12pF |
±10ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0191 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.576000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0192 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.576000 MHz |
16pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0192 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.576000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0193 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.576000 MHz |
16pF |
±10ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0193 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.576000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0194 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120000 MHz |
10pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0194 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0195 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120000 MHz |
10pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0195 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±2 ppm max. |
|
|
|
|
10-0196 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120000 MHz |
10pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0196 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0197 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120 MHz |
12pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0197 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0198 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0198 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0199 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120000 MHz |
16pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0199 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0200 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0200 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0201 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120 MHz |
16pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0201 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0202 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000 MHz |
12pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0202 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0203 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000 MHz |
12pF |
±20ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0203 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0204 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0204 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0205 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000 MHz |
12pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0205 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0206 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000 MHz |
16pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0206 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0207 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000 MHz |
16pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0207 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0208 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000 MHz |
12pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0208 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0209 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000 MHz |
12pF |
±10ppm |
±17ppm |
-40°C to +85°C |
| Part-Number: | 10-0209 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±17ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0210 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000000 MHz |
12pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0210 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0211 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000000 MHz |
16pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0211 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0212 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000000 MHz |
16pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0212 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0213 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000000 MHz |
16pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0213 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0214 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
30.000000 MHz |
12pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0214 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 30.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0215 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
30.000000 MHz |
12pF |
±10ppm |
±10ppm |
-40°C to +85°C |
| Part-Number: | 10-0215 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 30.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0216 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
30.000000 MHz |
12pF |
±10ppm |
±30ppm |
-40°C to +105°C |
| Part-Number: | 10-0216 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 30.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +105°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0217 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
30.000000 MHz |
12pF |
±10ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0217 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 30.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0218 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000000 MHz |
10pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0218 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0219 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000000 MHz |
10pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0219 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0220 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000 MHz |
12pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0220 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0221 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000 MHz |
12pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0221 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0222 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0222 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0223 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000 MHz |
12pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0223 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0224 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0224 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0225 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0225 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0226 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000 MHz |
18pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0226 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0227 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.000 MHz |
18pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0227 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0228 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560 MHz |
12pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0228 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0229 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560 MHz |
12pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0229 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0230 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560000 MHz |
16pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0230 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0231 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560000 MHz |
16pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0231 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0232 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560000 MHz |
16pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0232 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0233 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560000 MHz |
18pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0233 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0234 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560000 MHz |
18pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0234 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0235 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.745600 MHz |
10pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0235 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0236 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.745600 MHz |
10pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0236 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0237 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.745600 MHz |
12pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0237 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0238 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.745600 MHz |
12pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0238 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0239 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.745600 MHz |
12pF |
±10ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0239 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0240 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000 MHz |
10pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0240 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0241 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000 MHz |
10pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0241 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0242 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000 MHz |
10pF |
±10ppm |
±25ppm |
-40°C to +85°C |
| Part-Number: | 10-0242 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±25ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0243 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
40.000 MHz |
12pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0243 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 40.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0244 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
40.000 MHz |
12pF |
±30ppm |
±10ppm |
-40°C to +85°C |
| Part-Number: | 10-0244 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 40.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0245 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
37.500 MHz |
12pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0245 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 37.500 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0246 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
19.200 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0246 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 19.200 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0247 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.000 MHz |
16pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0247 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0248 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.000 MHz |
16pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0248 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0249 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
36.000 MHz |
18pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0249 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 36.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0250 |
UTECH |
THT11550 |
QRDS HC-49/S |
11.5 x 4.65 x 3.50 |
36.000000 MHz |
20pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0250 |
| Manufacturer: | UTECH |
| Series: | THT11550 |
| Type: | QRDS HC-49/S |
| Dimensions (mm): | 11.5 x 4.65 x 3.50 |
| Frequency: | 36.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0251 |
UTECH |
THT11550 |
QRDS HC-49/S |
11.5 x 4.65 x 3.50 |
25.000000MHz |
18pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0251 |
| Manufacturer: | UTECH |
| Series: | THT11550 |
| Type: | QRDS HC-49/S |
| Dimensions (mm): | 11.5 x 4.65 x 3.50 |
| Frequency: | 25.000000MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±5ppm max. |
|
|
|
|
10-0252 |
UTECH |
THT11550 |
QRDS HC-49/S
(Lead Cut:
3.5±0.5mm) |
11.5 x 4.65 x 3.50 |
25.000000 MHz |
18pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0252 |
| Manufacturer: | UTECH |
| Series: | THT11550 |
| Type: | QRDS HC-49/S
(Lead Cut:
3.5±0.5mm) |
| Dimensions (mm): | 11.5 x 4.65 x 3.50 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 20 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±5ppm max. |
|
|
|
|
10-0253 |
UTECH |
THT11550 |
QRDS HC-49/S
(Ammopack) |
11.5 x 4.65 x 3.50 |
25.000000 MHz |
18pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0253 |
| Manufacturer: | UTECH |
| Series: | THT11550 |
| Type: | QRDS HC-49/S
(Ammopack) |
| Dimensions (mm): | 11.5 x 4.65 x 3.50 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 20 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±5ppm max. |
|
|
|
|
10-0254 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.000000 MHz |
16pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0254 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0255 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.000000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0255 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0256 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.000000 MHz |
16pF |
±10ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0256 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0257 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
14.745600 MHz |
16pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0257 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0258 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
14.745600 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0258 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0259 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
14.745600 MHz |
16pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0259 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0261 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 × 2.0 × 0.55 |
20.000 MHz |
10pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0261 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 × 2.0 × 0.55 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0262 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 × 2.0 × 0.55 |
20.000 MHz |
10pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0262 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 × 2.0 × 0.55 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0263 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
12.000 MHz |
16pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0263 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0264 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
12.000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0264 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0265 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
12.000 MHz |
16pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0265 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0266 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
24.000 MHz |
12pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0266 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0 pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0267 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0267 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0268 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.000 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0268 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0269 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.000 MHz |
16pF |
±30ppm |
±100ppm |
-20°C to +70°C |
| Part-Number: | 10-0269 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0270 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
13.560000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0270 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0271 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
13.560000 MHz |
16pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0271 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0272 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
13.560000 MHz |
16pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0272 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0273 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
48.000000 MHz |
18pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0273 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 48.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0274 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
48.000000 MHz |
18pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0274 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 48.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0275 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
48.000000 MHz |
18pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0275 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 48.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0276 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000000MHz |
16pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0276 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000000MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0277 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000000 MHz |
16pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0277 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0278 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.513530 MHz |
9pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0278 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.513530 MHz |
| Load Capacitance CL: | 9pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0279 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432000 MHz |
12pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0279 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0280 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432 MHz |
12pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0280 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0281 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
18.432 MHz |
16pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0281 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0282 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
18.432 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0282 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0283 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
18.432 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0283 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0284 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
25.000 MHz |
16pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0284 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0285 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
25.000 MHz |
16pF |
±25ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0285 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±25ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0286 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.000 MHz |
18pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0286 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0287 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.000 MHz |
18pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0287 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0288 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.192 MHz |
12pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0288 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.192 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0289 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
20.000 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0289 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0290 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000000 MHz |
16pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0290 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0291 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 × 2.0 × 0.55 |
16.000000 MHz |
16pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0291 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 × 2.0 × 0.55 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0292 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 × 2.0 × 0.55 |
16.000000 MHz |
16pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0292 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 × 2.0 × 0.55 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0293 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 × 2.0 × 0.55 |
16.000000 MHz |
16pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0293 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 × 2.0 × 0.55 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0294 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.318180 MHz |
12pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0294 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.318180 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0295 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
16pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0295 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0296 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
16pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0296 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0297 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
16pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0297 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0298 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
16pF |
±10ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0298 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0299 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
40.000000 MHz |
20pF |
±10ppm |
±9ppm |
-20°C to +70°C |
| Part-Number: | 10-0299 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 40.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±9ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0300 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
18.432 MHz |
12pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0300 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 18.432 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0301 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000 MHz |
10pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0301 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0302 |
UTECH |
SMD6035-M4 |
QRS6 |
6.0 x 3.5 x 1.00 |
10.368 MHz |
15pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0302 |
| Manufacturer: | UTECH |
| Series: | SMD6035-M4 |
| Type: | QRS6 |
| Dimensions (mm): | 6.0 x 3.5 x 1.00 |
| Frequency: | 10.368 MHz |
| Load Capacitance CL: | 15pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0304 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000 MHz |
16pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0304 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0308 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000 MHz |
16pF |
±15ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0308 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±15ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 70 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0309 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 × 2.0 × 0.55 |
32.000 MHz |
8pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0309 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 × 2.0 × 0.55 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 8pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0310 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.368 MHz |
15pF |
±10ppm |
±5ppm |
-10°C to +60°C |
| Part-Number: | 10-0310 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.368 MHz |
| Load Capacitance CL: | 15pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±5ppm |
| Operating Temperature Range: | -10°C to +60°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0311 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
9.216 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0311 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 9.216 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0312 |
UTECH |
SMD6035-M4 |
QRS6 |
6.0 x 3.5 x 1.00 |
9.216 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0312 |
| Manufacturer: | UTECH |
| Series: | SMD6035-M4 |
| Type: | QRS6 |
| Dimensions (mm): | 6.0 x 3.5 x 1.00 |
| Frequency: | 9.216 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | |
| Equivalent Series Resistance (ESR): | |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | |
|
|
|
|
10-0313 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0313 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0314 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
16pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0314 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0315 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
16pF |
±20ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0315 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0316 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
18pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0316 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0317 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
18pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0317 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0318 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
18pF |
±10ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0318 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0319 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
16pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0319 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0320 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
16pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0320 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0321 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
16pF |
±10ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0321 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0322 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
18pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0322 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0323 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
18pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0323 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0324 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000 MHz |
18pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0324 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0325 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.000 MHz |
20pF |
±20ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0325 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0326 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
48.000 MHz |
7pF |
±10ppm |
±12ppm |
-30°C to +85°C |
| Part-Number: | 10-0326 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 48.000 MHz |
| Load Capacitance CL: | 7pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±12ppm |
| Operating Temperature Range: | -30°C to +85°C |
| Storage Temperature Range: | -40°C to +155°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | |
| Insulation Resistance: | 500 MΩ (Min.) at DC100V ±15V |
| Aging: | First year ±5ppm max. |
|
|
|
|
10-0327 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 x 2.0 x 0.55 |
40.000 MHz |
20pF |
±9ppm |
±9ppm |
-20°C to +70°C |
| Part-Number: | 10-0327 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 x 2.0 x 0.55 |
| Frequency: | 40.000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±9ppm |
| Frequency Tolerance over Temperature: | ±9ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0328 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
40.000 MHz |
20pF |
±9ppm |
±9ppm |
-20°C to +70°C |
| Part-Number: | 10-0328 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 40.000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±9ppm |
| Frequency Tolerance over Temperature: | ±9ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0707 |
UTECH |
SMD7050-M4 |
|
|
6.000000 MHz |
18pF |
±20ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0707 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M4 |
| Type: | |
| Dimensions (mm): | |
| Frequency: | 6.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 70 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0330 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +105°C |
| Part-Number: | 10-0330 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +105°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | ±3ppm max first year |
|
|
|
|
10-0331 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 × 2.0 × 0.55 |
16.000 MHz |
10pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0331 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 × 2.0 × 0.55 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -40°C to +105°C |
| Drive Level: | 1 uW to 100 µW ( Typical: 10 uW ) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | ±3ppm max first year |
|
|
|
|
10-0332 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
32.000 MHz |
10pF |
±10ppm |
±10ppm |
-10°C to +70°C |
| Part-Number: | 10-0332 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -10°C to +70°C |
| Storage Temperature Range: | -55°C to +105°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm |
| Shunt Capacitance: | 5pF max. (2pF typical) |
| Insulation Resistance: | |
| Aging: | Max. ±2ppm/first year, max. ±5ppm in 5 years |
|
|
|
|
10-0333 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
36.000 MHz |
18pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0333 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 36.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0334 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
20pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0334 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0335 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
16.000000 MHz |
10pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0335 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -40°C to +155°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 200 Ohm max. |
| Shunt Capacitance: | |
| Insulation Resistance: | 500 MΩ (Min.) at DC100V ±15V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0337 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000000 MHz |
16pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0337 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | max. ±10 ppm over 11 years, “over all tolerance” = ±35ppm max |
|
|
|
|
10-0338 |
UTECH |
THT26 |
TF-206 |
6.2 x 2.1 x 0.20 |
32.768 kHz |
12.5pF |
±20ppm |
-0.04 × 10-6 / °C2 max. |
-20°C to +70°C |
| Part-Number: | 10-0338 |
| Manufacturer: | UTECH |
| Series: | THT26 |
| Type: | TF-206 |
| Dimensions (mm): | 6.2 x 2.1 x 0.20 |
| Frequency: | 32.768 kHz |
| Load Capacitance CL: | 12.5pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | -0.04 × 10-6 / °C2 max. |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -40°C to +85°C |
| Drive Level: | 1µW max. |
| Equivalent Series Resistance (ESR): | 35 kOhm max. |
| Shunt Capacitance: | 0.8pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | ±3ppm max. first year |
|
|
|
|
10-0340 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
12pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0340 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0341 |
UTECH |
THT11550 |
HC-49/S |
11.5 x 4.65 x 3.50 |
26.000000 MHz |
17pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0341 |
| Manufacturer: | UTECH |
| Series: | THT11550 |
| Type: | HC-49/S |
| Dimensions (mm): | 11.5 x 4.65 x 3.50 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 17pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 15 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | Aging: max. ±10 ppm over 11 years, “over all tolerance” = ±35ppm max. |
|
|
|
|
10-0342 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
40.000000 MHz |
20pF |
±9ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0342 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 40.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±9ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0343 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
40.000000MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0343 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 40.000000MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max |
|
|
|
|
10-0344 |
UTECH |
SMD7050-M4 |
QRS7 |
7.0 x 5.0 x 1.00 |
7.372800 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0344 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M4 |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 7.372800 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0345 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
48.000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0345 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 48.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0346 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
13.560 MHz |
22pF |
±20ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0346 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 13.560 MHz |
| Load Capacitance CL: | 22pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0347 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
48.000 MHz |
7pF |
±10ppm |
±12ppm |
-30°C to +85°C |
| Part-Number: | 10-0347 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 48.000 MHz |
| Load Capacitance CL: | 7pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±12ppm |
| Operating Temperature Range: | -30°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0348 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
48.000 MHz |
8pF |
±10ppm |
±12ppm |
-30°C to +85°C |
| Part-Number: | 10-0348 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 48.000 MHz |
| Load Capacitance CL: | 8pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±12ppm |
| Operating Temperature Range: | -30°C to +85°C |
| Storage Temperature Range: | -40°C to +155°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | |
| Insulation Resistance: | 500 MΩ (Min.) at DC100V ±15V |
| Aging: | First year ±5ppm max. |
|
|
|
|
10-0349 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
25.000000 MHz |
20pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0349 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0352 |
UTECH |
SMD8038-P4 |
QTS8 |
7.9 x 3.7 x 2.40 |
32.768 kHz |
12.5pF |
±30ppm |
TC: -0,030ppm/°C² typ.,
-0,040ppm/°C² max. |
-40°C to +85°C |
| Part-Number: | 10-0352 |
| Manufacturer: | UTECH |
| Series: | SMD8038-P4 |
| Type: | QTS8 |
| Dimensions (mm): | 7.9 x 3.7 x 2.40 |
| Frequency: | 32.768 kHz |
| Load Capacitance CL: | 12.5pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | TC: -0,030ppm/°C² typ.,
-0,040ppm/°C² max. |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1μW Max. |
| Equivalent Series Resistance (ESR): | 50 kOhm max. |
| Shunt Capacitance: | 1.35pF Typ. |
| Insulation Resistance: | |
| Aging: | ±3ppm max. first year |
|
|
|
|
10-0353 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
12.000 MHz |
12pF |
±30ppm |
±100ppm |
-40°C to +125°C |
| Part-Number: | 10-0353 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +125°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0354 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.000 MHz |
12pF |
±30ppm |
±100ppm |
-40°C to +125°C |
| Part-Number: | 10-0354 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +125°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0355 |
UTECH |
THT11135 |
QRDU HC-49U |
11.5 x 5.00 x 13.50 |
16.000000 MHz |
30pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0355 |
| Manufacturer: | UTECH |
| Series: | THT11135 |
| Type: | QRDU HC-49U |
| Dimensions (mm): | 11.5 x 5.00 x 13.50 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 1µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 25 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0356 |
UTECH |
THT11135 |
QRDU HC-49U |
11.5 x 5.0 x 13.5 |
2.457600 MHz |
30pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0356 |
| Manufacturer: | UTECH |
| Series: | THT11135 |
| Type: | QRDU HC-49U |
| Dimensions (mm): | 11.5 x 5.0 x 13.5 |
| Frequency: | 2.457600 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 1µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 200 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0357 |
UTECH |
THT11135 |
QRDU HC-49U |
11.5 x 5.0 x 13.5 |
11.059200 MHz |
30pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0357 |
| Manufacturer: | UTECH |
| Series: | THT11135 |
| Type: | QRDU HC-49U |
| Dimensions (mm): | 11.5 x 5.0 x 13.5 |
| Frequency: | 11.059200 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 1µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 25 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0358 |
UTECH |
THT38 |
TF-308 |
8.2 x 3.1 x 0.30 |
32.768 kHz |
12.5pF |
±10ppm |
-0.04 × 10-6 / °C2 max. |
-20°C to +70°C |
| Part-Number: | 10-0358 |
| Manufacturer: | UTECH |
| Series: | THT38 |
| Type: | TF-308 |
| Dimensions (mm): | 8.2 x 3.1 x 0.30 |
| Frequency: | 32.768 kHz |
| Load Capacitance CL: | 12.5pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | -0.04 × 10-6 / °C2 max. |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -40°C to +85°C |
| Drive Level: | 1µW max. |
| Equivalent Series Resistance (ESR): | 50 kOhm max. |
| Shunt Capacitance: | 0.9pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | ±3ppm max. first year |
|
|
|
|
10-0360 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
16pF |
±15ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0360 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±15ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 100µW typ. 300µW max.) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0361 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 × 2.0 × 0.55 |
25.000000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0361 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 × 2.0 × 0.55 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0362 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
25.000000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0362 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0 pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0363 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
28.636300 MHz |
10pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0363 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 28.636300 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0364 |
UTECH |
SMD7050-M2 (2PAD) |
QRS7 |
7.0 x 5.0 x 1.00 |
8.000000 MHz |
20pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0364 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M2 (2PAD) |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 8.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0365 |
UTECH |
SMD7050-M4 |
QRS7 |
7.0 x 5.0 x 1.00 |
13.560000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0365 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M4 |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0366 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
24.000000 MHz |
18pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0366 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | 5ppm max. 1 year |
|
|
|
|
10-0367 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0367 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0368 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000 MHz |
16pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0368 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0369 |
UTECH |
SMD1350 |
QRSZ |
13.0 x 4.7 x 4.80 |
8.000 MHz |
30pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0369 |
| Manufacturer: | UTECH |
| Series: | SMD1350 |
| Type: | QRSZ |
| Dimensions (mm): | 13.0 x 4.7 x 4.80 |
| Frequency: | 8.000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | ±5ppm max. first year |
|
|
|
|
10-0370 |
UTECH |
SMD1350 |
QRSZ |
13.0 x 4.7 x 4.80 |
6.000 MHz |
30pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0370 |
| Manufacturer: | UTECH |
| Series: | SMD1350 |
| Type: | QRSZ |
| Dimensions (mm): | 13.0 x 4.7 x 4.80 |
| Frequency: | 6.000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 80 Ohm |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | ±5ppm max. first year |
|
|
|
|
10-0371 |
UTECH |
SMD1350 |
QRSZ |
13.0 x 4.7 x 4.80 |
4.000 MHz |
30pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0371 |
| Manufacturer: | UTECH |
| Series: | SMD1350 |
| Type: | QRSZ |
| Dimensions (mm): | 13.0 x 4.7 x 4.80 |
| Frequency: | 4.000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 120 Ohm |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | ±5ppm max. first year |
|
|
|
|
10-0372 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
25.000 MHz |
16pF |
±25ppm |
±25ppm |
-40°C to +85°C |
| Part-Number: | 10-0372 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±25ppm |
| Frequency Tolerance over Temperature: | ±25ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0373 |
UTECH |
THT11550 |
HC-49/S |
11.5 x 4.65 x 3.50 |
24.000 MHz |
20pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0373 |
| Manufacturer: | UTECH |
| Series: | THT11550 |
| Type: | HC-49/S |
| Dimensions (mm): | 11.5 x 4.65 x 3.50 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | ±3ppm max. first year |
|
|
|
|
10-0374 |
UTECH |
THT11550 |
HC-49/S |
11.5 x 4.65 x 3.50 |
27.000 MHz |
20pF |
±20ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0374 |
| Manufacturer: | UTECH |
| Series: | THT11550 |
| Type: | HC-49/S |
| Dimensions (mm): | 11.5 x 4.65 x 3.50 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 20 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | ±3ppm max. first year |
|
|
|
|
10-0375 |
UTECH |
SMD7050-M2 (2PAD) |
QRS7 |
7.0 x 5.0 x 1.00 |
10.000000 MHz |
12pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0375 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M2 (2PAD) |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0376 |
UTECH |
SMD7050-M4 |
QRS7 |
7.0 x 5.0 x 1.00 |
11.059200 MHz |
12pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0376 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M4 |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 11.059200 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0379 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
4.915200 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0379 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 4.915200 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 130 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±5ppm max. |
|
|
|
|
10-0380 |
UTECH |
THT11550 |
QRDS HC-49/S |
11.5 x 4.65 x 3.50 |
5.000000 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0380 |
| Manufacturer: | UTECH |
| Series: | THT11550 |
| Type: | QRDS HC-49/S |
| Dimensions (mm): | 11.5 x 4.65 x 3.50 |
| Frequency: | 5.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 150 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0671 |
UTECH |
HC-49/S |
QRSD |
10.21 x 4.80 x 4.20 |
36.0000 MHz |
20pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0671 |
| Manufacturer: | UTECH |
| Series: | HC-49/S |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 36.0000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±5 ppm max. |
|
|
|
|
10-0382 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
7.372800 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0382 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 7.372800 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 70 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±5ppm max. |
|
|
|
|
10-0383 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
14.745600 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0383 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±5ppm max. |
|
|
|
|
10-0384 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
8.000000 MHz |
20pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0384 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 8.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±5 ppm max. |
|
|
|
|
10-0385 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
12pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0385 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±2 ppm max. |
|
|
|
|
10-0386 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
40.000000 MHz |
20pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0386 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 40.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 25 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±2 ppm max. |
|
|
|
|
10-0387 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
33.3330 MHz |
18pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0387 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 33.3330 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0388 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
3.6864 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0388 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 3.6864 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 130 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0389 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
8.000 MHz |
30pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0389 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 8.000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0391 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000 MHz |
12pF |
±30ppm |
±50ppm |
-40°C to +125°C |
| Part-Number: | 10-0391 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +125°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 65 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0392 |
UTECH |
SMD7050-M2 (2PAD) |
QRS7 |
7.0 x 5.0 x 1.00 |
16.000 MHz |
12pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0392 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M2 (2PAD) |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0393 |
UTECH |
SMD5032-M2 |
QRS5 |
5.0 x 3.2 x 0.90 |
12.000 MHz |
12pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0393 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M2 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0394 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
27.120 MHz |
10pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0394 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 27.120 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0395 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 x 2.0 x 0.55 |
27.120 MHz |
10pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0395 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 x 2.0 x 0.55 |
| Frequency: | 27.120 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 100 µW max. |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0396 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
27.120 MHz |
10pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0396 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 27.120 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -40°C to +125°C |
| Drive Level: | 100 μW Max. |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | |
| Insulation Resistance: | 500 MΩ (Min.) at DC100V ±15V |
| Aging: | First year ±5ppm max. |
|
|
|
|
10-0397 |
UTECH |
SMD7050-M4 |
QRS7 |
7.0 x 5.0 x 1.00 |
25.000000 MHz |
16pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0397 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M4 |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0398 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
28.800000 MHz |
20pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0398 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 28.800000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 500 µW max. |
| Equivalent Series Resistance (ESR): | 35 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0399 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
5.000000 MHz |
30pF |
±50ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0399 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 5.000000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±50ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±5 ppm max. |
|
|
|
|
10-0400 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
24.000000 MHz |
20pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0400 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0401 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
27.000000 MHz |
20pF |
±20ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0401 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 27.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0402 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
28.800000 MHz |
20pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0402 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 28.800000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 35 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0403 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
25.000000 MHz |
18pF |
±20ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0403 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0404 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
12.000000 MHz |
18pF |
±20ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0404 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0405 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
18pF |
±20 ppm |
±30 |
-20°C to +70°C |
| Part-Number: | 10-0405 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±20 ppm |
| Frequency Tolerance over Temperature: | ±30 |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0406 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
18pF |
±20 ppm |
±30 |
-20°C to +70°C |
| Part-Number: | 10-0406 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±20 ppm |
| Frequency Tolerance over Temperature: | ±30 |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0407 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
32.000 MHz |
12pF |
±25 ppm “over all” |
-0 |
-40°C to +85°C |
| Part-Number: | 10-0407 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±25 ppm “over all” |
| Frequency Tolerance over Temperature: | -0 |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±2 ppm max. |
|
|
|
|
10-0408 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
5.000 MHz |
30pF |
±50ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0408 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 5.000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±50ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0409 |
UTECH |
SMD1350 |
QRSZ |
13.0 x 4.7 x 4.80 |
4.000 MHz |
30pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0409 |
| Manufacturer: | UTECH |
| Series: | SMD1350 |
| Type: | QRSZ |
| Dimensions (mm): | 13.0 x 4.7 x 4.80 |
| Frequency: | 4.000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 120 Ohm |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | ±5ppm max. first year |
|
|
|
|
10-0410 |
UTECH |
SMD1350 |
QRSZ |
13.0 x 4.7 x 4.80 |
4.000 MHz |
30pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0410 |
| Manufacturer: | UTECH |
| Series: | SMD1350 |
| Type: | QRSZ |
| Dimensions (mm): | 13.0 x 4.7 x 4.80 |
| Frequency: | 4.000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 120 Ohm |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | ±5ppm max. first year |
|
|
|
|
10-0411 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
5.000 MHz |
30pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0411 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 5.000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0412 |
UTECH |
HC-49/S |
QRSD |
10.21 x 4.80 x 4.20 |
2.4576 MHz |
30pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0412 |
| Manufacturer: | UTECH |
| Series: | HC-49/S |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 2.4576 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 200 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±5 ppm max. |
|
|
|
|
10-0414 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
14.7456 MHz |
12pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0414 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 14.7456 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0415 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.7456 MHz |
12pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0415 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.7456 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0416 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
12.000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0416 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0417 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
18pF |
±20ppm |
±20ppm |
-20°C to +70°C |
| Part-Number: | 10-0417 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0418 |
UTECH |
SMD8038-P4 |
QTS8 |
7.9 x 3.7 x 2.40 |
32.768 kHz |
12.5pF |
±20ppm |
TC: -0,030ppm/°C² typ., -0,040ppm/°C² max. |
-40°C to +85°C |
| Part-Number: | 10-0418 |
| Manufacturer: | UTECH |
| Series: | SMD8038-P4 |
| Type: | QTS8 |
| Dimensions (mm): | 7.9 x 3.7 x 2.40 |
| Frequency: | 32.768 kHz |
| Load Capacitance CL: | 12.5pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | TC: -0,030ppm/°C² typ., -0,040ppm/°C² max. |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1μW Max. |
| Equivalent Series Resistance (ESR): | 50 kOhm max. |
| Shunt Capacitance: | 1.35pF Typ. |
| Insulation Resistance: | |
| Aging: | ±3ppm max. first year |
|
|
|
|
10-0419 |
UTECH |
SMD7015-P4 |
QTS7 |
7.0 x 1.5 x 1.40 |
32.768 kHz |
12.5pF |
±20ppm |
-0.04ppm/°C max. |
-40°C to +85°C |
| Part-Number: | 10-0419 |
| Manufacturer: | UTECH |
| Series: | SMD7015-P4 |
| Type: | QTS7 |
| Dimensions (mm): | 7.0 x 1.5 x 1.40 |
| Frequency: | 32.768 kHz |
| Load Capacitance CL: | 12.5pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | -0.04ppm/°C max. |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1.0 W Max. |
| Equivalent Series Resistance (ESR): | 65 kOhm max. |
| Shunt Capacitance: | 0.8 pF Typ. |
| Insulation Resistance: | |
| Aging: | |
|
|
|
|
10-0420 |
UTECH |
SMD7015-P4 |
QTS7 |
7.0 x 1.5 x 1.40 |
32.768 kHz |
12.5pF |
±20 ppm |
-0.04ppm/°C max. |
-40°C to +85°C |
| Part-Number: | 10-0420 |
| Manufacturer: | UTECH |
| Series: | SMD7015-P4 |
| Type: | QTS7 |
| Dimensions (mm): | 7.0 x 1.5 x 1.40 |
| Frequency: | 32.768 kHz |
| Load Capacitance CL: | 12.5pF |
| Frequency Tolerance at 25°C: | ±20 ppm |
| Frequency Tolerance over Temperature: | -0.04ppm/°C max. |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1.0 W Max. |
| Equivalent Series Resistance (ESR): | 65 kOhm max. |
| Shunt Capacitance: | 0.8 pF Typ. |
| Insulation Resistance: | |
| Aging: | |
|
|
|
|
10-0421 |
UTECH |
SMD8038-P4 |
QTS8 |
7.9 x 3.7 x 2.40 |
32.768 kHz |
6pF |
±20ppm |
TC: -0,030ppm/°C² typ., -0,040ppm/°C² max. |
-40°C to +85°C |
| Part-Number: | 10-0421 |
| Manufacturer: | UTECH |
| Series: | SMD8038-P4 |
| Type: | QTS8 |
| Dimensions (mm): | 7.9 x 3.7 x 2.40 |
| Frequency: | 32.768 kHz |
| Load Capacitance CL: | 6pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | TC: -0,030ppm/°C² typ., -0,040ppm/°C² max. |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1μW Max. |
| Equivalent Series Resistance (ESR): | 50 kOhm max. |
| Shunt Capacitance: | 1.35pF Typ. |
| Insulation Resistance: | |
| Aging: | |
|
|
|
|
10-0422 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
18pF |
±20ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0422 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0423 |
UTECH |
SMD1350 |
QRSZ |
13.0 x 4.7 x 4.80 |
48.000000 MHz (3.OT) |
30pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0423 |
| Manufacturer: | UTECH |
| Series: | SMD1350 |
| Type: | QRSZ |
| Dimensions (mm): | 13.0 x 4.7 x 4.80 |
| Frequency: | 48.000000 MHz (3.OT) |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 80 Ohm |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | ±3ppm max. first year |
|
|
|
|
10-0425 |
UTECH |
HC-49/S |
QRSD |
10.21 x 4.80 x 4.20 |
5.000000 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0425 |
| Manufacturer: | UTECH |
| Series: | HC-49/S |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 5.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 150 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0426 |
UTECH |
SMD1350 |
QRSZ |
13.0 x 4.7 x 4.80 |
16.000000 MHz |
30pF |
±50ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0426 |
| Manufacturer: | UTECH |
| Series: | SMD1350 |
| Type: | QRSZ |
| Dimensions (mm): | 13.0 x 4.7 x 4.80 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±50ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | ±3ppm max. first year |
|
|
|
|
10-0428 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
8.000 MHz |
12pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0428 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 8.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0429 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
12.000 MHz |
30pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0429 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0430 |
UTECH |
SMD7050-M4 |
QRS7 |
7.0 x 5.0 x 1.00 |
14.7456 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0430 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M4 |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 14.7456 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0432 |
UTECH |
SMD7050-M4 |
QRS7 |
7.0 x 5.0 x 1.00 |
8.000 MHz |
12pF |
±50ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0432 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M4 |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 8.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±50ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0433 |
UTECH |
SMD7050-M2 (2PAD) |
QRS7 |
7.0 x 5.0 x 1.00 |
16.000 MHz |
12pF |
±50ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0433 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M2 (2PAD) |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±50ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0434 |
UTECH |
SMD1350 |
QRSZ |
13.0 x 4.7 x 4.80 |
12.000 MHz |
30pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0434 |
| Manufacturer: | UTECH |
| Series: | SMD1350 |
| Type: | QRSZ |
| Dimensions (mm): | 13.0 x 4.7 x 4.80 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | ±5ppm max. first year |
|
|
|
|
10-0436 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
12.000 MHz |
10pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0436 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0437 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
24.000000 MHz |
18pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0437 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0438 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
26.000000 MHz |
10pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0438 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0440 |
UTECH |
SMD7050-M4 |
QRS7 |
7.0 x 5.0 x 1.00 |
10.000000 MHz |
20pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0440 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M4 |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0441 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
25.000000 MHz |
13pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0441 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 13pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0442 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
24.576000 MHz |
13pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0442 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 24.576000 MHz |
| Load Capacitance CL: | 13pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0443 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
24.000000 MHz |
10pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0443 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0444 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
3.579545 MHz |
16pF |
±50ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0444 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 3.579545 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±50ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 150 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0445 |
UTECH |
SMD7050-M4 |
QRS7 |
7.0 x 5.0 x 1.00 |
13.560000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0445 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M4 |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0446 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.736000MHz |
15pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0446 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.736000MHz |
| Load Capacitance CL: | 15pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0447 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000 MHz |
16pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0447 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0448 |
UTECH |
SMD1350 |
QRSZ |
13.0 x 4.7 x 4.80 |
32.000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0448 |
| Manufacturer: | UTECH |
| Series: | SMD1350 |
| Type: | QRSZ |
| Dimensions (mm): | 13.0 x 4.7 x 4.80 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 30 Ohm |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | ±5ppm max. first year |
|
|
|
|
10-0449 |
UTECH |
SMD7015-P4 |
QTS7 |
7.0 x 1.5 x 1.40 |
32.768 kHz |
12.5pF |
±10ppm |
-0.04ppm/°C max. |
-40°C to +85°C |
| Part-Number: | 10-0449 |
| Manufacturer: | UTECH |
| Series: | SMD7015-P4 |
| Type: | QTS7 |
| Dimensions (mm): | 7.0 x 1.5 x 1.40 |
| Frequency: | 32.768 kHz |
| Load Capacitance CL: | 12.5pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | -0.04ppm/°C max. |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1.0 W Max. |
| Equivalent Series Resistance (ESR): | 65 kOhm max. |
| Shunt Capacitance: | 0.8 pF Typ. |
| Insulation Resistance: | |
| Aging: | ±3ppm max. first year |
|
|
|
|
10-0450 |
UTECH |
SMD1350 |
QRSZ |
13.0 x 4.7 x 4.80 |
4.000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0450 |
| Manufacturer: | UTECH |
| Series: | SMD1350 |
| Type: | QRSZ |
| Dimensions (mm): | 13.0 x 4.7 x 4.80 |
| Frequency: | 4.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 120 Ohm |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | ±5ppm max. first year |
|
|
|
|
10-0451 |
UTECH |
SMD1350 |
QRSZ |
13.0 x 4.7 x 4.80 |
20.000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0451 |
| Manufacturer: | UTECH |
| Series: | SMD1350 |
| Type: | QRSZ |
| Dimensions (mm): | 13.0 x 4.7 x 4.80 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | ±5ppm max. first year |
|
|
|
|
10-0452 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
48.000 MHz |
8pF |
±10ppm |
±12ppm |
-30°C to +85°C |
| Part-Number: | 10-0452 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 48.000 MHz |
| Load Capacitance CL: | 8pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±12ppm |
| Operating Temperature Range: | -30°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 5.0 pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0454 |
UTECH |
SMD5032-M2 |
QRS5 |
5.0 x 3.2 x 0.90 |
25.000 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0454 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M2 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0459 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000000 MHz |
16pF |
±50ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0459 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±50ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0461 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
24.000000 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0461 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0462 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
48.020000 MHz |
7pF |
±10ppm |
±12ppm |
-30°C to +85°C |
| Part-Number: | 10-0462 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 48.020000 MHz |
| Load Capacitance CL: | 7pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±12ppm |
| Operating Temperature Range: | -30°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 5.0 pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0463 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
16.000000 MHz |
20pF |
±30ppm |
±50ppm |
-40°C to +105°C |
| Part-Number: | 10-0463 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 20pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +105°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0464 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.000000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +105°C |
| Part-Number: | 10-0464 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +105°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0465 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 × 2.0 × 0.55 |
16.000000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0465 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 × 2.0 × 0.55 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 uW to 100µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0466 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
11.059200 MHz |
16pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0466 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 11.059200 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0467 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
24.000000 MHz |
8pF |
±40ppm |
OA ("Over all") |
-40°C to +85°C |
| Part-Number: | 10-0467 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 24.000000 MHz |
| Load Capacitance CL: | 8pF |
| Frequency Tolerance at 25°C: | ±40ppm |
| Frequency Tolerance over Temperature: | OA ("Over all") |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max., 20 Ohm typ. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | ±1ppm at 1 year, ±10ppm over 10 years |
|
|
|
|
10-0468 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
40.000000 MHz |
12pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0468 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 40.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0471 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.736 MHz |
10pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0471 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.736 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0472 |
UTECH |
SMD3215-M2 |
QTS3 |
3.2 x 1.5 x 0.90 |
32.768 kHz |
12.5pF |
±20ppm |
-0,03ppm/°C² typ.
-0,04ppm/°C² max. |
-40°C to +85°C |
| Part-Number: | 10-0472 |
| Manufacturer: | UTECH |
| Series: | SMD3215-M2 |
| Type: | QTS3 |
| Dimensions (mm): | 3.2 x 1.5 x 0.90 |
| Frequency: | 32.768 kHz |
| Load Capacitance CL: | 12.5pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | -0,03ppm/°C² typ.
-0,04ppm/°C² max. |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 0.1µW max. |
| Equivalent Series Resistance (ESR): | 70 kOhm max. |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | |
|
|
|
|
10-0473 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000 MHz |
10pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0473 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0474 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000 MHz |
18pF |
±10ppm |
±15ppm |
-20°C to +85°C |
| Part-Number: | 10-0474 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0475 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
50.000 MHz |
19pF |
±10ppm |
±15ppm |
-20°C to +85°C |
| Part-Number: | 10-0475 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 50.000 MHz |
| Load Capacitance CL: | 19pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±2 ppm max. |
|
|
|
|
10-0476 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
12pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0476 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±2 ppm max. |
|
|
|
|
10-0477 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000 MHz |
12pF |
±30ppm |
±100ppm |
-40°C to +85°C |
| Part-Number: | 10-0477 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±100ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±2 ppm max. |
|
|
|
|
10-0480 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
8.000000 MHz |
30pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0480 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 8.000000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0481 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
13.560000 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0481 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0482 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
16.000000 MHz |
12pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0482 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0488 |
UTECH |
SMD3215-M2 |
QTS3 |
3.2 x 1.5 x 0.90 |
32.768 kHz |
9pF |
±20ppm |
-0,03ppm/°C² typ.
-0,04ppm/°C² max. |
-40°C to +85°C |
| Part-Number: | 10-0488 |
| Manufacturer: | UTECH |
| Series: | SMD3215-M2 |
| Type: | QTS3 |
| Dimensions (mm): | 3.2 x 1.5 x 0.90 |
| Frequency: | 32.768 kHz |
| Load Capacitance CL: | 9pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | -0,03ppm/°C² typ.
-0,04ppm/°C² max. |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 0.1µW max. |
| Equivalent Series Resistance (ESR): | 70 kOhm max. |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | |
|
|
|
|
10-0702 |
UTECH |
SMD1612-M4 |
QRSA |
1.6 x 1.2 x 0.30 |
38.400000 MHz |
9pF |
±10ppm |
±12ppm |
-30°C to +85°C |
| Part-Number: | 10-0702 |
| Manufacturer: | UTECH |
| Series: | SMD1612-M4 |
| Type: | QRSA |
| Dimensions (mm): | 1.6 x 1.2 x 0.30 |
| Frequency: | 38.400000 MHz |
| Load Capacitance CL: | 9pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±12ppm |
| Operating Temperature Range: | -30°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 100 μW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0 pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0491 |
UTECH |
SMD1612-M4 |
QRSA |
1.6 x 1.2 x 0.30 |
26.000 MHz |
8pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0491 |
| Manufacturer: | UTECH |
| Series: | SMD1612-M4 |
| Type: | QRSA |
| Dimensions (mm): | 1.6 x 1.2 x 0.30 |
| Frequency: | 26.000 MHz |
| Load Capacitance CL: | 8pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 100 μW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 5.0 pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0498 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
32.000 MHz |
10pF |
±10ppm |
±10ppm |
-20°C to +75°C |
| Part-Number: | 10-0498 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 32.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +75°C |
| Storage Temperature Range: | -40°C to +85°C |
| Drive Level: | 100 μW Max. |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | |
| Insulation Resistance: | 500 MΩ (Min.) at DC100V ±15V |
| Aging: | First year ±5ppm max. |
|
|
|
|
10-0499 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
26.000 MHz |
9pF |
±10ppm |
±10ppm |
-20°C to +75°C |
| Part-Number: | 10-0499 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 26.000 MHz |
| Load Capacitance CL: | 9pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +75°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0 pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0501 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
8.000000 MHz |
16pF |
±30ppm |
±50ppm |
-40°C to +105°C |
| Part-Number: | 10-0501 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 8.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +105°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0502 |
UTECH |
SMD5032-M2 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
18pF |
±10ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0502 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M2 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0503 |
UTECH |
HC-49/S3SMD |
QRSC |
10.21 x 4.80 x 2.70 |
8.192000 MHz |
12pF |
±30ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0503 |
| Manufacturer: | UTECH |
| Series: | HC-49/S3SMD |
| Type: | QRSC |
| Dimensions (mm): | 10.21 x 4.80 x 2.70 |
| Frequency: | 8.192000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0504 |
UTECH |
HC-49/SSMD |
QRSE |
10.21 x 4.80 x 3.20 |
13.560000 MHz |
18pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0504 |
| Manufacturer: | UTECH |
| Series: | HC-49/SSMD |
| Type: | QRSE |
| Dimensions (mm): | 10.21 x 4.80 x 3.20 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0505 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 × 2.0 × 0.55 |
16.000000 MHz |
8pF |
±15ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0505 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 × 2.0 × 0.55 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 8pF |
| Frequency Tolerance at 25°C: | ±15ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 uW to 100µW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0506 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.745600 MHz |
16pF |
±8ppm |
±12ppm |
-20°C to +70°C |
| Part-Number: | 10-0506 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±8ppm |
| Frequency Tolerance over Temperature: | ±12ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0507 |
UTECH |
HC-49/SSMD |
QRSE |
10.21 x 4.80 x 3.20 |
10.368000 MHz |
10pF |
±10ppm |
±10ppm |
-10°C to +60°C |
| Part-Number: | 10-0507 |
| Manufacturer: | UTECH |
| Series: | HC-49/SSMD |
| Type: | QRSE |
| Dimensions (mm): | 10.21 x 4.80 x 3.20 |
| Frequency: | 10.368000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -10°C to +60°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | ±3 ppm max. first year, ±10 ppm after 8 years |
|
|
|
|
10-0508 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
7pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0508 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 7pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0509 |
UTECH |
SMD8038-P4 |
QTS8 |
7.9 x 3.7 x 2.40 |
32.768 kHz |
7pF |
±20ppm |
TC: -0,030ppm/°C² typ., -0,040ppm/°C² max. |
-40°C to +85°C |
| Part-Number: | 10-0509 |
| Manufacturer: | UTECH |
| Series: | SMD8038-P4 |
| Type: | QTS8 |
| Dimensions (mm): | 7.9 x 3.7 x 2.40 |
| Frequency: | 32.768 kHz |
| Load Capacitance CL: | 7pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | TC: -0,030ppm/°C² typ., -0,040ppm/°C² max. |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1μW Max. |
| Equivalent Series Resistance (ESR): | 50 kOhm max. |
| Shunt Capacitance: | 1.35pF Typ. |
| Insulation Resistance: | |
| Aging: | ±3ppm max. first year |
|
|
|
|
10-0510 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000 MHz |
18pF |
±10ppm |
±15ppm |
-20°C to +70°C |
| Part-Number: | 10-0510 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0511 |
UTECH TECHNOLOGY CO.,LTD |
SMD1350 |
QRSZ |
13.0 x 4.7 x 4.80 |
16.000000 MHz |
16pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0511 |
| Manufacturer: | UTECH TECHNOLOGY CO.,LTD |
| Series: | SMD1350 |
| Type: | QRSZ |
| Dimensions (mm): | 13.0 x 4.7 x 4.80 |
| Frequency: | 16.000000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW |
| Equivalent Series Resistance (ESR): | 40 Ohm |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | ±3ppm max. first year |
|
|
|
|
10-0512 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
26.000 MHz |
10pF |
±20ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0512 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 26.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0513 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
26.000 MHz |
12pF |
±10ppm |
±15ppm |
-40°C to +75°C |
| Part-Number: | 10-0513 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 26.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +75°C |
| Storage Temperature Range: | -40°C to +125°C |
| Drive Level: | 100 μW Max. |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | |
| Insulation Resistance: | 500 MΩ (Min.) at DC100V ±15V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0514 |
UTECH |
SMD2012-C2 |
QTS2 |
2.0 x 1.2 x 0.60 |
32.768 kHz |
7pF |
±20ppm |
TC = -0.03 ppm / °C2 max. |
-40°C to +85°C |
| Part-Number: | 10-0514 |
| Manufacturer: | UTECH |
| Series: | SMD2012-C2 |
| Type: | QTS2 |
| Dimensions (mm): | 2.0 x 1.2 x 0.60 |
| Frequency: | 32.768 kHz |
| Load Capacitance CL: | 7pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | TC = -0.03 ppm / °C2 max. |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 0.5µW max. |
| Equivalent Series Resistance (ESR): | 90 kOhm max. |
| Shunt Capacitance: | |
| Insulation Resistance: | |
| Aging: | |
|
|
|
|
10-0515 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
16.000 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0515 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0516 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000 MHz |
18pF |
±25ppm |
±25ppm |
-40°C to +85°C |
| Part-Number: | 10-0516 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±25ppm |
| Frequency Tolerance over Temperature: | ±25ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0517 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
20.000 MHz |
18pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0517 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 20.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0518 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
16.000 MHz |
18pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0518 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 16.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0519 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
25.000 MHz |
18pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0519 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 25.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0520 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
13.000000 MHz |
18pF |
±20ppm |
±50ppm |
-40°C to +85°C |
| Part-Number: | 10-0520 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 13.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0521 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000 MHz |
18pF |
±20ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0521 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±20ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0522 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
12.000000 MHz |
12pF |
±30ppm |
±50ppm |
-40°C to +125°C |
| Part-Number: | 10-0522 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +125°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0523 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
25.000000 MHz |
12pF |
±30ppm |
±50ppm |
-40°C to +125°C |
| Part-Number: | 10-0523 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -40°C to +125°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0524 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
14.745600 MHz |
12pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0524 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1 ppm max. |
|
|
|
|
10-0525 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
10.000000 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0525 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 10.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW |
| Equivalent Series Resistance (ESR): | 100 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0526 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
12.000000 MHz |
18pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0526 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 12.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0527 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
3.686400 MHz |
18pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0527 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 3.686400 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 120 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0528 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
20.020000 MHz |
18pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0528 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 20.020000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0529 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
8.000000 MHz |
15pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0529 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 8.000000 MHz |
| Load Capacitance CL: | 15pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0530 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
8.000 MHz |
13pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0530 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 8.000 MHz |
| Load Capacitance CL: | 13pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0531 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
16.384 MHz |
13pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0531 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 16.384 MHz |
| Load Capacitance CL: | 13pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0532 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
7.680 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0532 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 7.680 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0533 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
12.800 MHz |
15pF |
±10ppm |
±10ppm |
-40°C to +85°C |
| Part-Number: | 10-0533 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 12.800 MHz |
| Load Capacitance CL: | 15pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0534 |
UTECH |
SMD2520-M4 |
QRS2 |
2.5 × 2.0 × 0.55 |
24.000 MHz |
12pF |
±10ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0534 |
| Manufacturer: | UTECH |
| Series: | SMD2520-M4 |
| Type: | QRS2 |
| Dimensions (mm): | 2.5 × 2.0 × 0.55 |
| Frequency: | 24.000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 uW to 100µW |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0535 |
UTECH |
SMD3225-M4 |
QRS3 |
3.2 x 2.5 x 0.70 |
48.000 MHz |
10pF |
±8ppm |
±10ppm |
-30°C to +85°C |
| Part-Number: | 10-0535 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRS3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 48.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±8ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -30°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW |
| Equivalent Series Resistance (ESR): | 22 Ohm max. |
| Shunt Capacitance: | 5.0pF Max. ( Typical: 3.0 pF) |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3 ppm max. |
|
|
|
|
10-0536 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
48.000 MHz |
10pF |
±8ppm |
±12ppm |
-30°C to +85°C |
| Part-Number: | 10-0536 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 48.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±8ppm |
| Frequency Tolerance over Temperature: | ±12ppm |
| Operating Temperature Range: | -30°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 22 Ohm max. |
| Shunt Capacitance: | 5.0 pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1ppm max. |
|
|
|
|
10-0537 |
UTECH |
SMD5032-M4 |
QRS5 |
5.0 x 3.2 x 0.90 |
11.0592 MHz |
12pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0537 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M4 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 11.0592 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0538 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
48.000 MHz |
10pF |
±10ppm |
±12ppm |
-30°C to +85°C |
| Part-Number: | 10-0538 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 48.000 MHz |
| Load Capacitance CL: | 10pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±12ppm |
| Operating Temperature Range: | -30°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 5.0 pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0539 |
UTECH |
SMD7050-M4 |
QRS7 |
7.0 x 5.0 x 1.00 |
27.000 MHz |
16pF |
±30ppm |
±50ppm |
-20°C to +70°C |
| Part-Number: | 10-0539 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M4 |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 27.000 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±50ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0540 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
25.000000 MHz |
18pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0540 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 30 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0541 |
UTECH |
SMD3225-M4 |
QRD3 |
3.2 x 2.5 x 0.70 |
14.745600 MHz |
16pF |
±10ppm |
±15ppm |
-40°C to +85°C |
| Part-Number: | 10-0541 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRD3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±15ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 100 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0542 |
UTECH |
SMD3225-M4 |
QRD3 |
3.2 x 2.5 x 0.70 |
19.660800 MHz |
16pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0542 |
| Manufacturer: | UTECH |
| Series: | SMD3225-M4 |
| Type: | QRD3 |
| Dimensions (mm): | 3.2 x 2.5 x 0.70 |
| Frequency: | 19.660800 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 100 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0546 |
UTECH |
SMD5032-M2 |
QRS5 |
5.0 x 3.2 x 0.90 |
36.000000 MHz |
18pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0546 |
| Manufacturer: | UTECH |
| Series: | SMD5032-M2 |
| Type: | QRS5 |
| Dimensions (mm): | 5.0 x 3.2 x 0.90 |
| Frequency: | 36.000000 MHz |
| Load Capacitance CL: | 18pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10uW to 100µW ( Typical: 10uW ) |
| Equivalent Series Resistance (ESR): | 50 Ohm max. |
| Shunt Capacitance: | 7.0pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0547 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
13.560000 MHz |
30pF |
±30ppm |
±30ppm |
-20°C to +70°C |
| Part-Number: | 10-0547 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 13.560000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 40 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0548 |
UTECH |
HC-49/SMD |
QRSD |
10.21 x 4.80 x 4.20 |
8.000000 MHz |
30pF |
±30ppm |
±30ppm |
-40°C to +85°C |
| Part-Number: | 10-0548 |
| Manufacturer: | UTECH |
| Series: | HC-49/SMD |
| Type: | QRSD |
| Dimensions (mm): | 10.21 x 4.80 x 4.20 |
| Frequency: | 8.000000 MHz |
| Load Capacitance CL: | 30pF |
| Frequency Tolerance at 25°C: | ±30ppm |
| Frequency Tolerance over Temperature: | ±30ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW to 500 µW (Typical: 10 μW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0 pF Max. |
| Insulation Resistance: | |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0549 |
UTECH |
SMD7050-M4 |
QRS7 |
7.0 x 5.0 x 1.00 |
14.745600 MHz |
16pF |
±10ppm |
±10ppm |
-20°C to +70°C |
| Part-Number: | 10-0549 |
| Manufacturer: | UTECH |
| Series: | SMD7050-M4 |
| Type: | QRS7 |
| Dimensions (mm): | 7.0 x 5.0 x 1.00 |
| Frequency: | 14.745600 MHz |
| Load Capacitance CL: | 16pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±10ppm |
| Operating Temperature Range: | -20°C to +70°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 1 µW to 100µW (Typical: 10µW) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 7.0pF Max. |
| Insulation Resistance: | More than 500MΩ @ DC 100V |
| Aging: | First year ±3ppm max. |
|
|
|
|
10-0564 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
26.000000 MHz |
12pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0564 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 26.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0 pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1ppm max. |
|
|
|
|
10-0566 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
25.000000 MHz |
12pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0566 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 25.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 80 Ohm max. |
| Shunt Capacitance: | 5.0 pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1ppm max. |
|
|
|
|
10-0567 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
40.000000 MHz |
12pF |
±10ppm |
±20ppm |
-40°C to +85°C |
| Part-Number: | 10-0567 |
| Manufacturer: | UTECH |
| Series: | SMD2016-M4 |
| Type: | QRS1 |
| Dimensions (mm): | 2.0 x 1.6 x 0.50 |
| Frequency: | 40.000000 MHz |
| Load Capacitance CL: | 12pF |
| Frequency Tolerance at 25°C: | ±10ppm |
| Frequency Tolerance over Temperature: | ±20ppm |
| Operating Temperature Range: | -40°C to +85°C |
| Storage Temperature Range: | -55°C to +125°C |
| Drive Level: | 10 μW (Typical) / 100 μW (Max.) |
| Equivalent Series Resistance (ESR): | 60 Ohm max. |
| Shunt Capacitance: | 5.0 pF max. |
| Insulation Resistance: | More than 500MOhm @ DC 100V |
| Aging: | First year ±1ppm max. |
|
|
|
|
10-0568 |
UTECH |
SMD2016-M4 |
QRS1 |
2.0 x 1.6 x 0.50 |
25.000000 MHz |
12pF |
±10ppm |
±20ppm |
-20°C to +75°C |
|
